10-40450-22S datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> Connector bracket> 10-40450-22S

10-40450-22S: DescriptionConnector Accessory, Gasket,; CategoryThe connector Connector bracket; File Size22KB，1 Pages; ManufacturerAmphenol; Websitehttp://www.amphenol.com/

Download Datasheet Parametric View All

10-40450-22S Overview

Connector Accessory, Gasket,

10-40450-22S Parametric

Parameter Name	Attribute value
Maker	Amphenol
Reach Compliance Code	unknown
Is Samacsys	N
Assembly name	GASKET
Connector bracket type	CONNECTOR ACCESSORY
DIN compliance	NO
IEC compliance	NO
MIL compliance	NO
used for	RECEPTACLE
Base Number Matches	1

Preview

Download Datasheet

View All

GT Connector accessories for Bombardier

10-40450, 10-36675, 10-580649 sealing gaskets

PLAIN FLAT GASKET

The Amphenol

plain flat gasket of synthetic rubber material

is provided to take complete advantage of waterproof and

pressure sealing features. It is for use with the flange

mounted receptacle.

SHIELDING GASKET

This flat gasket is provided to give the maximum in connector

performance. Its special feature is in providing the maximum

radio shielding under difficult conditions of high receiver sen-

sitivity and low signal strength while retaining the sealing

characteristics of the plain gasket. This gasket is for use with

the flange mounting receptacle.

LOW TEMPERATURE GASKET

This gasket is provided for applications where the major

requirement is resistance to the injurious effects of extremely

low temperature. Even at temperatures as low as –67°F this

gasket retains its resiliency and will seal a pressure differen-

tial of 30 psi.

Additional versions of gaskets are available including low

smoke zero halogen, and also high temperature and conduc-

tive types. Consult Amphenol lndustrial Operations, Sidney

NY, for further information.

Order Data for

Front Panel Mount Gaskets

± .010

.172

.203

.219

10-40450-10

10-40450-14

10-40450-16

10-40450-18

10-40450-20

10-40450-22

10-40450-24

10-40450-28

10-40450-32

10-40450-36

10-40450-40

10-40450-10S

10-40450-14S

10-40450-16S

10-40450-18S

10-40450-20S

10-40450-22S

10-40450-24S

10-40450-28S

10-40450-32S

10-40450-36S

10-40450-40S

Front Panel

Plain Version

Front Panel

Shielding Version

Front Panel

Low Temperature

Version

10-36675-10

10-36675-14

10-36675-16

10-36675-18

10-36675-20

10-36675-22

10-36675-24

10-36675-28

10-36675-32

10-36675-36

10-36675-40

Front Panel

Low Smoke ZH

Version

LS-40450-10

LS-40450-14

LS-40450-16

LS-40450-18

LS-40450-20

LS-40450-22

LS-40450-24

LS-40450-26

LS-40450-32

LS-40450-36

LS-40450-40

Installation Dimensions

Front Panel

Versions

+ .016

– .000

.625

.875

1.000

1.125

1.250

1.375

1.500

1.750

2.000

2.188

2.438

Rear Panel

Version

+ .016

– .000

.724

.976

1.087

1.220

1.354

1.480

1.618

1.846

2.110

2.354

2.587

Shell

Size

10SL

14S

16S

± .010

.719

.906

.969

1.063

1.156

1.250

1.375

1.563

1.750

1.938

2.188

+ .016

– .000

1.000

1.188

1.281

1.375

1.500

1.625

1.750

2.000

2.250

2.500

2.750

Installation Dimensions

Front Panel

Versions

+ 0.4

– 0.0

15.9

22.2

25.4

28.57

31.75

34.9

38.1

44.45

50.8

55.57

61.92

Rear Panel

Version

+ 0.4

– 0.0

18.4

24.8

27.6

31.0

34.4

37.6

41.1

46.9

53.6

59.8

65.7

Order Data for

Rear Panel Mount Gaskets

Rear Panel

Plain Version

± 0.2

4.36

5.15

5.56

10-580649-11

10-580649-14

10-580649-16

10-580649-18

10-580649-20

10-580649-22

10-580649-24

10-580649-26

10-580649-32

10-580649-36

10-580649-40

Rear Panel

Low Smoke ZH

Version

LS-580649-11

LS-580649-14

LS-580649-16

LS-580649-18

LS-580649-20

LS-580649-22

LS-580649-24

LS-580649-26

LS-580649-32

LS-580649-36

LS-580649-40

Shell

Size

10SL

14S

16S

± 0.2

18.2

23.0

24.6

27.0

29.4

31.8

34.9

39.7

44.5

49.2

55.6

+ 0.4

– 0.0

25.4

30.2

32.5

35.0

38.1

41.2

44.5

50.8

57.2

63.5

69.9
