2-175425-2: DescriptionCONNECTOR, 10 CONTACT(S), FEMALE, STRAIGHT TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE; CategoryThe connector The connector; File Size105KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

2-175425-2 Overview

CONNECTOR, 10 CONTACT(S), FEMALE, STRAIGHT TWO PART BOARD CONNECTOR, CRIMP, RECEPTACLE

2-175425-2 Parametric

Parameter Name	Attribute value
Objectid	1420495720
Reach Compliance Code	unknown
Other features	AMPMODU
Body/casing type	RECEPTACLE
Connector type	BOARD CONNECTOR
Contact to complete cooperation	GOLD (15)
Contact completed and terminated	TIN LEAD
Contact point gender	FEMALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e0
MIL compliance	NO
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	CABLE
Number of rows loaded	2
Options	GENERAL PURPOSE
Termination type	CRIMP
Total number of contacts	10
UL Flammability Code	94V-0

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

PC B C onnectors

Product Feature Selector

> Product Details

2-175425-2 Product Details

Live Product Chat

Product View

.100 AMPMODU Headers, Housings & Contacts

Not re vie we d for R oHS C om plia nce

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

2-175425-2

T E I nternal N umber: 2 - 1 7 5 4 2 5 - 2

Product Highlights:

Housing

Preloaded

Number of Positions = 10

Housing Type = Receptacle

C ontact Type = Receptacle

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

None Available

Product Specifications:

Interconnection System, AMPMODU Mod IV 1/2

(PDF, English)

No title

(PDF, English)

EC ONOMY AMPMODU C ONNEC TOR

(PDF, English)

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Housing

Number of Positions

= 10

Mating C onnector Lock

= Without

Strain Relief

= Without

Mating Polarization = Without

Keyed

= No

C onnector Series

= Mod IV

Wire Termination Type = C rimp

C losed Entry = With

Board Standoff = Without

Mechanical Attachment:

Preloaded = Yes

Termination Related Features:

Solder Tail C ontact Plating = Tin-Lead

Termination Post Length (mm [in]) = 2.60 [0.102]

Body Related Features:

Housing Type

= Receptacle

Number of Rows

= Dual

C enterline, Matrix (mm [in])

= 2.54 x 2.54 [.100 x .100]

Contact Related Features:

C ontact Type = Receptacle

C ontact Mating Area Plating Material

= Gold (15)

C ontact Base Material = Phosphor Bronze

C ontact Termination Type = Through Hole

Housing Related Features:

Housing C olor

= Black

Housing Entry Style = Top

Housing Flammability Rating = UL 94V-0

Housing Material = Thermoplastic

Industry Standards:

RoHS/ELV C ompliance

= Not reviewed for ELV/RoHS compliance

Lead Free Solder Processes

= Not reviewed for lead free solder

process

Conditions for Usage:

Terminate To

= Printed C ircuit Board

High Temperature C ompatible = Yes

Other:

Brand = AMP

Additional Information:

Product Line Information
