DB101 THRU DB107
SINGLE-PHASE GLASS PASSIVATED SILICON BRIDGE RECTIFIER
Reverse Voltage – 50 to 1000 V
Forward Current – 1 A
Features
•
Glass passivated chip junction
•
Low forward voltage drop
•
High surge overload rating of 50 A peak
•
Ideal for printed circuit board
Mechanical Data
•
Case: Molded plastic, DB
•
Epoxy: UL 94V-0 rate flame retardant
•
Terminals: Leads solderable per MIL-STD-202,
method 208 guaranteed
•
Mounting position: Any
Absolute Maximum Ratings and Characteristics
Ratings at 25
O
C ambient temperature unless otherwise specified. Single phase, half wave, 60 Hz, resistive or
inductive load. For capacitive load, derate current by 20%.
Parameter
Symbols
DB101 DB102 DB103 DB104 DB105 DB106 DB107 Units
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
at T
A
= 25
O
C
at T
A
= 125
O
C
I
R
C
J
R
θ
JA
R
θ
JL
T
J
,T
S
50
35
50
100
70
100
200
140
200
400
280
400
1
50
1.1
5
500
25
40
15
-55 to +150
O
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current at T
A
= 40
O
C
Peak Forward Surge Current 8.3 ms Single Half-sine-wave
Superimposed on Rated Load (JEDEC Method)
Maximum Forward Voltage at 1 A
Maximum Reverse Current at Rated
DC Blocking Voltage
Typical Junction Capacitance
1)
Typical Thermal Resistance
2)
Typical Thermal Resistance
2)
Operating and Storage Temperature Range
1)
2)
600
420
600
800
560
800
1000
700
1000
V
V
V
A
A
V
µA
pF
C/W
C/W
O
O
C
Measured at 1 MHz and applied reverse voltage of 4 V
Thermal resistance from junction to ambient and from junction to lead mounted on P.C.B with 0.5 X 0.5" (13 X 13
mm) copper pads.
SEMTECH ELECTRONICS LTD.
(Subsidiary
of Sino-Tech International Holdings Limited, a company
listed on the Hong Kong Stock Exchange, Stock Code: 724)
®
Dated :01/04/2006 H
