POWER INDUCTORS <SMD Type: CDRH ***/A Series>
Type: CDRH15D78/A
◆
Product Description
・15.5×15.5mm
Max. (L×W ) ,
8.0 mm Max. Height.
・Inductance
Range: 10½220µH
・Rated
current range: 1.17½5.38A.
・In
addition to the standards versions shown here, custom inductors are also
available to meet your exact requirements.
◆
Feature
・Magnetically
shielded construction.
・High
reliable inductors, suitable to use in high temperature environment(125℃).
・Ideally
for automotive applications as converter inductors.
・RoHS
Compliance.
◆
Dimensions (mm)
15.0±0.5
8.0 Max.(7.8 Typ.)
14.0±0.5
6.0±0.5
6±
2.
3
0.
15.0±0.5
Ma
x.
21
.9
：Terminal
4
0.
0±
3.
◆
Land Pattern (mm)
16.0
5.0
6
5. 0
4.
◆Schematics(Bottom)
16.0
5.0
(10μH½56μH)
(68μH½220μH)
Please refer to the sales offices on our website for a representative near you
www.sumida.com
6.0±0.5
14.0±0.5
4
0.
0±
3.
1)
2.
5
(1
0.
±
.1
18
45°
1/2
***
POWER INDUCTORS <SMD Type: CDRH ***/A Series>
Type: CDRH15D78/A
◆
Specification
Part Name
※
CDRH15D78/ANP-1ØØM□
CDRH15D78/ANP-12ØM□
CDRH15D78/ANP-15ØM□
CDRH15D78/ANP-18ØM□
CDRH15D78/ANP-22ØM□
CDRH15D78/ANP-27ØM□
CDRH15D78/ANP-33ØM□
CDRH15D78/ANP-39ØM□
CDRH15D78/ANP-47ØM□
CDRH15D78/ANP-56ØM□
CDRH15D78/ANP-68ØM□
CDRH15D78/ANP-82ØM□
CDRH15D78/ANP-1Ø1M□
CDRH15D78/ANP-121MC□
CDRH15D78/ANP-151M□
CDRH15D78/ANP-181M□
CDRH15D78/ANP-221M□
※
Description of part name
Ｃ
D R H 1 5 D
7
8
/ A N P
－
1 Ø Ø M
□
Stamp
100M
120M
150M
180M
220M
270M
330M
390M
470M
560M
680M
820M
101M
121M
151M
181M
221M
Inductance
［Within½
(μH）
100kHz/1V
10±20%
12±20%
15±20%
18±20%
22±20%
27±20%
33±20%
39±20%
47±20%
56±20%
68±20%
82±20%
100±20%
120±20%
150±20%
180±20%
220±20%
D.C.R.(mΩ)
Max.(Typ.)
(at 20℃)
16.3(13)
18.8(15)
20.0(16)
25.0(20)
27.5(22)
36.3(29)
37.5(30)
41.3(33)
43.8(35)
57.5(46)
67.5(54)
75.0(60)
100.0(80)
130.0(104)
152.5(122)
167.5(134)
216.3(173)
Rated current
(A)(at 125℃)
※1
5.38
4.42
4.14
3.90
3.55
3.20
2.75
2.68
2.52
2.26
2.05
1.87
1.70
1.55
1.38
1.28
1.17
Ｂ
Ｃ
Box
Carrier Tape
※1
Rated current: The DC current at which the inductance decreases to 65 % of it’s nominal
value or when
△t＝30℃,
whichever is lower
(Ta=125℃).
Please refer to the sales offices on our website for a representative near you
www.sumida.com
2/2
