BIAS TEES
2.4mm, 50 kHz - 50 GHz, 25 Volts / 150 mA
SPECIFICATIONS:
Models: 8810EMFX-50, 8810EFFX-50, 8810EMMX-50, 8810EFMX-50
Electrical:
Frequency Range
VSWR:
Insertion Loss:
100 kHz
50 kHz - 18 GHz
18 - 50 GHz
Impedance
Isolation (RF to Bias Port):
250 kHz - 26 GHz
100 kHz - 50 GHz
DC Voltage
DC Current
Rise Time (10% - 90%)
50 kHz - 50 GHz
1.80:1 Max.
0.5dB Typical
1.5dB Max.
3.0dB Max.
50 ohms
50dB Typical
30dB Typ.
25 VDC Max.
150 mA Max.
< 9 pS Typical
Insertion Loss (dB)
Typical performance from 50 kHz - 50 GHz
0
-1.0
-2.0
-3.0
-4.0
-5.0
.00001
.0001
.001
.01
Mechanical:
2.4mm Connectors
Mates with 1.85mm & V* Connectors
.1
FREQ (GHz)
1
10
100
50
Gold Plated Beryllium Copper
Gold Plated Beryllium Copper
Aluminum with Chemical Conv. Coating
or Gold Plated Brass
Passivated Stainless Steel
Nickel Plated Brass
3.50
3.00
2.50
2.00
1.50
1.00
.00001
.0001
.001
.01
Conductors
Housing
SMA Connectors
Mates with MIL-STD-348
VSWR
BNC Connectors
Mates with MIL-STD-348
2.00
1.50
1.00
.1
FREQ (GHz)
1
10
100
50
*V is a trademark of Anritsu Corp.
.50 [12.70]
DC Input Connector Options
Solder Post, X=1
BNC Female, X=3
.25 [6.35]
.244
[6.20]
.489 [12.42]
Centered
DC Input
(SMA Female
Connector shown)
Option X = 2
3X Ø.102 [Ø2.59]
THRU
Model
Numbers
8810EMFX-YY
8810EFFX-YY
8810EMMX-YY
8810EFMX-YY
Connector
Configuration Port
AC + DC
AC
Female
Male
Female
Male
Female
Male
Male
Overall
Length
Max.
1.63 [41.40]
1.75 [44.45]
1.63 [41.40]
1.060
[26.92]
Cent.
AC + DC
Port
1.20
[30.48]
AC Port
Female 1.60 [40.64]
.19 [4.83]
Overall
Length
.63 [16.00]
HOW TO ORDER:
Model Number:
8810EYYX-50
Base Number
DC Connector Type
1 = Solder Post
2 = SMA Female Conn.
3 = BNC Female Conn.
Ordering Examples:
Model Number:
8810EFF2-50
50 KHz - 50 GHz, 2.4mm Fem/Fem
SMA Female DC Connector Type
Model Number:
8810EMF1-50
50 KHz - 50 GHz, 2.4mm Male/Fem
Solder Post DC Connector Type
8810E; REV L
Note: Dimensions in Brackets are Expressed in Millimeters and are for Reference Only.
Design, specifications are subject to change without notice. Contact factory for technical
specifications before purchasing and/or use.
Aeroflex / Inmet, Inc.
• 300 Dino Drive, Ann Arbor, MI 48103 • U.S.A.
888-244-6638 or 734-426-5553 • FAX: 734-426-5557
www.aeroflex-inmetcorp.com • sales@aeroflex-inmetcorp.com
