THICK FILM SIP NETWORKS
.
RCD CL101S
.
RCD CL101
RESISTORS CAPACITORS COILS DELAY LINES
CL SERIES -
Low Profile
C SERIES -
High Power
Low cost, widest selection in the industry!
Term.W is
RoHS
4-pin through 14-pin standard (2 through
compliant
20-pin sizes available on special order)
RoHS
& 260°C
compatible
CL Series low-profile available from stock
(configuration1 & 2 in 6, 8, and 10-pin)
Wide resis. range: 10Ω to 3MΩ std., 1Ω to 1000M avail.
Bulk packaging is standard, tape or magazine tube avail.
R/2R Ladder Networks
(Config. 7) offer 1/2LSB accuracy
from 4 to 10 bits
←
New high density Sips, an RCD exclusive!
.
RCD C101
OPTION V
OPTION S
OPTION P
OPTION N
OPTION F
OPTION C
-
-
-
-
-
-
+200°C temperature Range
Super high density (.070” pin spacing)
Pulse tolerant design
Narrowline design (.070” thick)
Flameproof coating
Copper alloy terminals
STANDARD CONFIGURATIONS
Configuration No. 1
>
>
>
>
>
>
>
>
>
>
>
>
>
>
>
Also available in custom circuits with multiple values/capacitors/
diodes, increased power & voltage, tolerance & TC matching, longer
pins, special marking, military burn-in, resis. values 1Ω to 1000M, etc.
Configuration No. 2
>
>
>
>
>
>
>
>
>
>
>
>
DIMENSIONS
.095 [2.4] Max.
Opt. N= .070±.008
[1.8±.2]
. . . . . .
>
>
>
>
>
>
→
←
←
Length=0.1” X No. of pins max
→
Pin #1
1
1
.
C=.315 [8] Max.
CL=.195 [5] Max.
↑
↓
Configuration No. 3
Configuration No. 4
. .
. .
>
>
>
>
R1
>
R1
>
1
.
.
>
>
>
>
>
>
>
>
>
>
>
>
R2
>
R2
>
R2
>
R2
>
R2
>
R2
>
.
.
>
>
R1
>
.
.
.
>
>
R1
>
.
.
.
>
>
R1
>
.
.
.
>
>
R1
>
.
.
1
>
>
>
.
>
>
>
.
>
>
>
.
>
>
>
.
>
>
>
.
>
>
>
.011 [.28]
→ ←
.020 [.5]
Dimensions: Inch [mm]
→ ← →
←
.100 ± .01 [2.54 ± .25]
↑
.102 [2.6] Min.
↓
Opt.S=.070± .01 [1.78 ±.25]
Configuration No. 5
>
>
>
>
>
>
>
>
>
>
>
>
Configuration No. 6
vvv vvv vvv vvv vvv
Config. No. 7 R/2R
R
R
R
1
1
>
>
>
>
>
>
1
>
2R
>
2R
>
>
vvv vvv vvv
2R
>
2R
>
2R
>
>
>
>
SINGLE RESISTOR
PACKAGE POWER RATING*
POWER RATING*
RCD
Type Config. Config. Config.
4-Pin 6-Pin 7-Pin 8-Pin 9-Pin 10-Pin 12-Pin
1,3,4,5,6
2
3, 7
C
.3W
.5W
.17W 1W 1.5W 1.75W 2W 2.25W 2.5W 3W
CL
.2W
.3W
.125W** .5W
1W 1.25W 1.5W 1.75W
2W
2.5W
* Reduce wattage ratings by 1/3 for Opt.S **Config. 7 n/a in CL Series
GND LSB
MSB OUT
STANDARD VALUES- C
onfig. 1, 2, 4, 5, 6:
10Ω to 3M in E-24 values (preferred values in bold type)-
10,
11,
12,
13,
15,
16,
18,
20,
22,
24,
27,
30,
33,
36,
39,
43,
47,
51,
56,
62,
68,
75,
82,
91
DERATING
% OF RATED POWER
(Series C and CL)
% OF RATED POWER
DERATING
120
100
80
60
40
20
0
(Option V)
120
100
80
60
40
20
0
25
50
75
100
125
AMBIENT TEMPERATURE (°C)
150
STANDARD VALUES -
Config. 3, Dual Terminator, R
1
/R
2
:
81/130
120/195
121/195
160/260
162/260
180/390
220/270
220/330
330/390
330/470
330/680
3K/6.2K
R/2R LADDER NETWORKS
(Config.7): 4Bit/6-pin, 5Bit/7-pin,
6Bit/8-pin, 7Bit/9-pin, 8Bit/10-pin, 9Bit/11-pin, and 10Bit/12-pin.
Available in Series C (low profile Series CL n/a). Linearity accuracy is
1/2LSB. Standard values are 5KΩ, 10KΩ, 25KΩ, 50KΩ, & 100KΩ ±2%.
40
80 120 160 200 240
AMBIENT TEMPERATURE (°C)
TYPICAL PERFORMANCE SPECIFICATIONS
Tolerance
Temperature Coefficient
TCR Tracking
Operating Temperature
Max. Working Voltage
Short Time Overload
Resis. to Solder Heat
Moisture Resistance
Terminal Strength
Thermal Shock
Load Life (1000 hours)
Temperature Cycling
Shock and Vibration
Lead Solderability
Marking
Terminals
2% Standard (1%, 5% avail.)
±100ppm typ (±250ppm <50
Ω
& >2.2M)
50PPM typical
-55°C to +125°C (+200°C Opt.V)
200V Series C, 100V Series CL & Opt.S
±0.5% (2.5x rated V, 5S, nte 2xW)
±0.25% (350°C, 5S)
±1%
±0.25%
±0.5%
±1.0%
±0.5%
±0.25%
Meets MIL-R-83401
Pin #1 ID, resis value, & tol as minimum
Solder plated steel typ., copper alloy* avail.
P/N DESIGNATION:
Type:
CL=low profile (std), C=high power
Number of Pins
CL 08 2
- 102 - G B
W
Configuration Number
Options:
V,S,P,N,F,C (leave blank if std)
Resis.Code 1%:
3 signif. figures & multiplier,
(e.g. 10R0=10Ω, 1000=100Ω, 1001=1K, 1004=1M)
Resis.Code 2%-5%:
2 signif. figures & multiplier,
(e.g. 100=10Ω, 101=100Ω, 102=1K, 103=10K, 104=100K, 105=1M)
When comprised of 2 res.values (config.3&7) separate
with /, e.g. 181/391=180Ω/390Ω
Tolerance Code:
G=2% (standard), F=1%, J=5%
Packaging:
B=bulk, A3=3 pin taping ammo pack, M=magazine tube
Opt. TC:
50=50ppm,101=100ppm (leave blank if standard)
Termination:
W= Lead-free, Q= Tin/Lead (leave blank if either is acceptable)
* RCD recommends use of copper alloy terminals (opt. C) in aqueous cleaning systems
RCD Components Inc,
520 E.Industrial Park Dr, Manchester, NH, USA 03109
rcdcomponents.com
Tel: 603
-
669
-
0054 Fax: 603
-
669
-
5455 Email:sales@rcdcomponents.com
FA032B Sale of this product is in accordance with GF-061. Specifications subject to change without notice.
