AH
SPECIFICATIONS
Electrical Ratings
Sealing Degree
Electrical Life
Contact Resistance
Actuation Force
Actuator Travel
Dielectric Strength:
Insulation Resistance
Operating Temperature
Storage Temperature
1A @ 24VDC
1A @ 125VAC
0.5A @ 250VAC
IP65
50,000 cycles typical
< 50 mΩ initial
550 +/- 50gF
2.5 +/- .3mm
2000Vrms min (contact to contact)
2000Vrms min (contact to LED)
> 100MΩ min
-25°C to 70°C
-25°C to 70°C
MATERIALS
←
RoHS COMPLIANT
Actuator
LED Lens
Threaded Body
Nut
Terminal Support
Inner Switch Body
Contacts
Terminals
Stainless Steel Black Anodized Aluminum
PC
Stainless Steel, Black Anodized Aluminum
Stainless Steel
PBT
PC
Silver Alloy
Brass, Tin Plated, Epoxy Sealed
ORDERING INFORMATION
1. Series:
AH
1
N
B
S
B
AH
2. Number of Poles:
1 = SPST NO + SPST NC
3. Latching Option:
N = Momentary
4. Actuator Style:
A = Flush actuator, non-illuminated
B = Flush actuator, ring illuminated
C = Flush actuator, dot illuminated
5. Switch Finish:
S = Stainless Steel
B = Black
6. First LED Color:
Blank = No LED
B = Blue
R = Red
W = White
Y = Yellow
O = Orange
G = Green
**For Bicolor LED option, White only available in single color
7. Second LED Color:
B = Blue
Blank = No LED
O = Orange
R = Red
Y = Yellow
G = Green
8. LED Voltage:
Blank = No LED
24 = 24V
N = No internal resistor in series with the LED
6 = 6V
110 = 110V
12 = 12V
220 = 220V
12
www.citswitch.com
page
6
phone – 763.535.2339 fax – 763.535.2194
AH
DIMENSIONS
**Terminals are epoxy sealed
**Terminals are epoxy sealed
**Terminals are epoxy sealed
A
B
C
LED CHARACTERISTICS
LED Ratings
Reverse Voltage
Forward Current (avg)
Forward Current (peak)
Reverse Current V
R
= 5V
Power Dissipation
Operating & Storage Temperature
Forward Voltage (typ.), I
F
= 20mA
Forward Voltage (max.), I
F
= 20mA
Wavelength at Peak Emmission, I
F
= 20mA
Spectral Line Half-Width, I
F
= 20mA
Luminous Intensity, I
F
= 20mA
Viewing Angle
V
R
I
F
I
FS
I
R
P
T
T
A
V
F
V
F
λ
P
∆λ
LI
Θ
R
5
25
120
10
80
2.1
2.4
635
14
120
145
Y
5
25
120
10
80
2.1
2.5
592
12
120
145
COLORS
G
B
O
5
5
5
30
30
25
160
160
120
10
10
10
120
120
80
-40~ +85
3.3
3.3
2.0
3.6
3.6
2.3
516
463
606
28
20
12
170
100
120
145
145
145
W
5
30
160
10
120
3.0
3.6
N/A
N/A
700
145
Units
V
mA
mA
µA
mW
°C
V
V
nm
nm
mcd
Deg
SCHEMATIC & PANEL CUT OUT
SPST NO + SPST NC
(SINGLE COLOR LED)
SPST NO + SPST NC
(DUAL COLOR LED)
BOTTOM VIEW
PANEL CUT OUT
www.citswitch.com
page
7
phone – 763.535.2339 fax – 763.535.2194
