STANDARD POWER INDUCTORS - THRU HOLE
DB1
TRADITIONAL
Pb
DB1LF
*
PART
NUMBER
COMPLIANT
RoHS
Wirewound, Power Line Choke, Radial
L µH
@ 1 kHz
DCR
OHMS
MAX
SATURATION
CURRENT
A DC
FERRITE CORE
DB1-221†
2.2
0.004
47.0
DB1-331†
3.3
0.005
40.0
DB1-391†
3.9
0.006
36.0
DB1-471†
4.7
0.007
32.0
DB1-561†
5.6
0.007
29.0
DB1-681†
6.8
0.007
26.0
DB1-821†
8.2
0.008
24.5
DB1-102
10
0.009
21.2
DB1-122
12
0.010
19.0
DB1-152
15
0.011
17.5
DB1-182
18
0.015
16.5
DB1-222
22
0.017
15.8
DB1-272
27
0.025
14.4
DB1-332
33
0.033
13.2
DB1-392
39
0.040
11.8
DB1-472
47
0.050
11.0
DB1-562
56
0.050
10.0
DB1-602
60
0.060
9.6
DB1-682
68
0.063
8.9
DB1-822
82
0.065
8.2
DB1-103
100
0.072
7.5
DB1-123
120
0.100
5.8
DB1-153
150
0.140
5.6
DB1-183
180
0.150
5.1
DB1-223
220
0.172
4.3
DB1-273
270
0.240
4.1
DB1-333
330
0.262
3.8
DB1-393
390
0.300
3.3
DB1-473
470
0.396
3.2
DB1-563
560
0.430
2.9
All part numbers provide 10% tolerance on inductance
† Provide 20% tolerance on inductance
Custom designs are available to meet your specific requirements; please contact factory
11.8
10.5
9.6
9.0
9.0
9.0
9.0
9.0
9.0
7.2
7.2
5.7
4.7
4.1
4.0
3.3
3.3
3.0
3.0
2.9
2.8
2.4
2.0
1.9
1.8
1.6
1.5
1.4
1.2
1.1
0.500 (12.70)
0.500 (12.70)
0.500 (12.70)
0.500 (12.70)
0.500 (12.70)
0.500 (12.70)
0.500 (12.70)
0.500 (12.70)
0.500 (12.70)
0.500 (12.70)
0.500 (12.70)
0.480 (12.19)
0.480 (12.19)
0.480 (12.19)
0.480 (12.19)
0.480 (12.19)
0.480 (12.19)
0.480 (12.19)
0.480 (12.19)
0.500 (12.70)
0.500 (12.70)
0.470 (11.94)
0.470 (11.94)
0.470 (11.94)
0.470 (11.94)
0.470 (11.94)
0.470 (11.94)
0.470 (11.94)
0.470 (11.94)
0.470 (11.94)
0.0508 (1.29)
0.0508 (1.29)
0.0508 (1.29)
0.0508 (1.29)
0.0508 (1.29)
0.0508 (1.29)
0.0508 (1.29)
0.0508 (1.29)
0.0508 (1.29)
0.0453 (1.15)
0.0453 (1.15)
0.0403 (1.02)
0.0359 (0.91)
0.0359 (0.91)
0.0320 (0.81)
0.0320 (0.81)
0.0320 (0.81)
0.0320 (0.81)
0.0285 (0.72)
0.0285 (0.72)
0.0285 (0.72)
0.0253 (0.64)
0.0253 (0.64)
0.0253 (0.64)
0.0253 (0.64)
0.0201 (0.57)
0.0201 (0.57)
0.0201 (0.57)
0.0201 (0.57)
0.0179 (0.45)
CURRENT
RATING
A DC
E
DIM
DIMENSIONS
LEAD
DIAMETER
*Add “LF” suffix for RoHS requirement. Example: DB1-221LF
E
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
NOTES:
LEAD DIA
0.650
(16.51)
MAX
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 35°C temperature
rise at an ambient temperature of 90°C
• Saturation Current is the approximate value that
will cause a 10% drop in inductance as indicated
in the table
• Leads tinned to within 0.062 in. of body
• Epoxy-insulated core
E
0.135
(3.43)
LEAD DIA
0.650
(16.51)
MAX
0.500 ± 0 .062
(12.7 ± 1.57)
0.825
(20.96) MAX
in. (mm)
PACKAGING SPECS:
Bulk only
0.135
(3.43)
*LEADS TINNED TO WITHIN .062 OF BODY
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
0.825
0.500 ± 0 .062
032113
Discrete Device
