REVISION B
(IPL1-110-02-XXX-DH-K-TR SHOWN)
C
IPL1-1XX-02-XXX-DH-K-TR
FIG. 1
No OF POSITIONS
-02 THRU -25 (PER ROW)
LEAD STYLE
-02: DOUBLE HORIZONTAL
(USE T-1S64-XX-XXX)
2 MAX SWAY
(TYP)
.025 0.64 SQ. REF
PLATING SPECIFICATION
-F: FLASH SELECTIVE (USE T-1S64-XX-F)
-L: LIGHT SELECTIVE (USE T-1S64-XX-L)
-S: SELECTIVE (USE T-1S64-XX-S)
-STL: SELECTIVE TIN/LEAD(USE T-1S64-XX-STL)
TAPE AND REEL
(SEE NOTES 9 & 12)
POLARIZATION
-K: KEYED POLARIZATION
ROW SPECIFICATION
-DH: DOUBLE HORIZONTAL
(No. OF POS. x .100[2.54]) + .075[1.91]
C
(No. OF POS. - 1) x .100[2.54]
.130 3.30
01
02
.250 6.35 REF
.100 2.54
.270 6.86 REF
.040 1.02 REF
.100 2.54 REF
.100 2.54 (TYP)
SEE NOTE 4
2 MAX TOE
(TYP)
(No. OF POS. x .100[2.54]) + .160[4.06] REF
"A"
IPL1-XX-DH-X
.300 7.62 REF
SEE NOTE 7
.220 5.59
WT-28-01-T
T-1S64-09-XXX
SEE NOTE 10
SEE NOTE 8
T-1S64-16-XXX
"A"
.023 0.57 REF (TYP)
.076 1.93 REF (TYP)
2 MAX SWAY (TYP)
C
.100 2.54
(TYP)
.025 0.64 SQ. REF
(TYP)
(No. OF POS. - 1) x .100[2.54]
NOTES:
C
.010[0.25]
SECTION "A"-"A"
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MINIMUM TERMINAL /WELD TAB RETENTION: 1.0LB.[4.4N}
3. PARTS TO BE MOLDED TO POSITION.
4. POST MUST BE WITHIN .005[0.13] OF EACH OTHER.
5. ALL PIN TO PIN DIMENSIONS TO BE MEASURED FROM TIP TO TIP.
6. DIMENSION TO BE MEASURED AT BEND.
7. TIP TO BE FLUSH TO .010[0.254] BELOW TOP OF SHROUD.
8. THIS NUMBER REPRESENTS THE NUMBER OF POSITIONS PER ROW
ONLY AND IS NOT INTENDED TO BE USED IN POSITION NUMBERING.
9. PARTS TO BE PACKAGED IN TAPE AND REEL.
10. INDENTION FROM WELD TAB CARRIER IS ALLOWABLE.
11. WELD TABS TO BE INSERTED WHILE ON CARRIER.
12. FOR QUANTITIES TO 49 PIECES, NO LEADER, TRAILER, OR REEL WILL BE SUPPLIED.
FOR QUANTITIES 50-124 PIECES, NO LEADER OR TRAILER WILL BE SUPPLIED.
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01 [0.3]
2
.XXX: .005 [0.13]
.XXXX: .0020 [0.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
INSULATOR: L.C.P. COLOR: BLACK
TERMINAL: PHOS BRONZE
.100[2.54] DOUBLE ROW TERMINAL ASSEMBLY
F:\DWG\MISC\MKTG\IPL1-1XX-02-XXX-DH-K-TR-MKT.SLDDRW
BY:
T NEWTON 02/29/2008
IPL1-1XX-02-XXX-DH-K-TR
SHEET
1
OF
2
REVISION B
.101 2.57
.108 2.73
C
WT-28-01-T
C
C
IN-PROCESS 1
(SEE NOTE 11)
.001 0.03 MAX
.003 0.08 MAX
C
C
.003 0.08 MAX
.006 [.15] MAX
B
COPLANARITY VIEWS
T-1S64-09-XXX
.220 5.59 REF
.530 13.46
REF
.235
- .010
5.97
- 0.25
+.000
0.00
.220 5.59 REF
.216 5.49
C
.806 20.47
REF
.511±.010 12.98±0.254
45°
(TYP)
T-1S64-16-XXX
C
.442 11.22
IN-PROCESS 2
IN-PROCESS 3
IN-PROCESS 4
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
IN-PROCESS 5
52°
(TYP)
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.100[2.54] DOUBLE ROW TERMINAL ASSEMBLY
F:\DWG\MISC\MKTG\IPL1-1XX-02-XXX-DH-K-TR-MKT.SLDDRW
BY:
T NEWTON 02/29/2008
IPL1-1XX-02-XXX-DH-K-TR
SHEET
2
OF
2
