REVISION AE
DO NOT
SCALE FROM
THIS PRINT
.1332 3.384 REF
C2-A-MV
{(No OF POSITIONS x .01969[.50])
+ .2468[6.3]}
C
BSH-XXX-01-X-D-XX-XX
No OF POSITIONS
-030, -40, -050, -060, -090,
**-120, **-150, *-180
(PER ROW)
**= SEE NOTE 10
.2850 7.239
REF
LEAD STYLE
-01: .1280 [3.25]
OPTION
-TR: TAPE & REEL
(120 POSITION MAX)
OPTION
-A: ALIGNMENT PINS
(USE BSH-XXX-01-D-A)
-LC: LOCKING CLIPS
(USE LC-08-TM-01) (SEE NOTE 13)
ROW SPECIFICATION
-D: DOUBLE (USE BSH-XXX-01-D)
(No OF POSITIONS -1) x .01969[.50]
02
.2450 6.223
REF
01
.0200 0.508 REF
.1500 3.810 REF
PLATING SPECIFICATION
-F: 3µ" FLASH SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAILS
(SEE NOTES 7, 9 & 12)
-L: 10µ" LIGHT SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAILS
BSH-XXX-01-D
(SEE NOTE 9 & 12)
-H: 30µ" HEAVY GOLD IN CONTACT AREA, 3µ" ON TAILS
.0197±.003 0.500±0.08 (TYP)
(SEE NOTE 9 &12)
-C: 50µ" ELECTRO-POLISHED SELECTIVE IN CONTACT AREA,
.042 1.07 REF
MATTE TIN ON TAILS
C5-B,I-MV
C
(SEE NOTE 9 &12)
+.005
* = NOT RELEASED FOR PRODUCTION
.165
- .001
4.191
+0.13
- 0.03
SEE NOTE 11
C-126-21-X
(SEE NOTE 12)
AE
C
C1-B,I-MV
C1
C4-A-MV
.0550 1.397
"A"
.1200 3.048 REF
C
C3-E-OG
.1280
- .0010
3.251
- 0.025
(SEE NOTE 6)
+.0030
+0.076
SEE TABLE 1
"A"
.0100 0.254 REF
.0060 0.152 REF
LC-08-TM-01
.070 1.765 REF
.2950 7.493 REF
BSH-XXX-01-D-A
.0980 2.489 REF
.0425 1.080 REF
-LC: LOCKING CLIP OPTION SHOWN
SEE NOTE 11
.0375 0.953
REF
SECTION "A"-"A"
SCALE 5 : 1
CRITICAL DIMENSION INSPECTION INSTRUCTION
TABLE
R
.0375 0.953 REF
NOTES:
.0350 0.889 REF
(No OF POSITIONS x .01969 [.5001])
+ .2018 [5.126] REF
ASSEMBLY OPERATION
IN-PROCESS INSPECTION
INSPECT CODE B
FILL C-126-21-X
ADD -LC OPTION
C1, C2, C5
C4
1.
CX-X-XX
REPRESENTS A CRITICAL DIMENSION.
-A: ALIGNMENT PIN OPTION SHOWN
2. NOTE DELETED.
3. BURR ALLOWANCE: .0015 [.038] MAX.
4. MINIMUM PUSHOUT FORCE: 6 OZ.
5. MAXIMUM ALLOWABLE BOW: .002 [.051] INCH/INCH AFTER ASSEMBLY.
6. MAX VARIENCE OF .002 [.051]
7. -L PLATING CAN BE SUBSTITUDED FOR -F PLATING.
8. ASP-65067-01 IS A BSH-050-01-L-D-A. WITH OR WITHOUT -TR.
9. MAY SUBSTITUTE C-126-01-X FOR C-126-21-X.
10. FOR NEWAPPLICATIONS REQUIRING THESE POSITIONS, PLEASE
CONTACT SAMTEC INTERCONNECT PROCESSING GROUP.
11. SIDE WALLS MAY BE RIBBED TO AVOID BOW
12. -090, -120, -150 & *-180 POSITION PARTS USE C-269-11-X. DO NOT SUB C-126-XX-X.
13. DUE TO THE HIGH AMOUNT OF INSERTION FORCE NEEDED, THE -LC OPTION
IS NOT COMPATIBLE WITH AUTO PLACEMENT. SAMTEC RECOMMENDS MANUAL
PLACEMENT FOR ALL ASSEMBLIES WITH THE -LC OPTION.
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
.XX: .01 [.25]
2
.XXX: .005 [.13]
.XXXX: .0020 [.050]
MATERIAL:
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
DECIMALS
ANGLES
DO NOT SCALE DRAWING
SHEET SCALE: 1:0.666667
DESCRIPTION:
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
FLAMMABILITY RATING: UL 94V-O
INSULATOR: BLACK LCP
CONTACT: PHOS BRONZE
F:\DWG\MISC\MKTG\BSH-XXX-01-X-D-XX-XX-MKT.SLDDRW
.5mm DOUBLE ROW SOCKET ASSEMBLY
DWG. NO.
BY:
DEAN P
BSH-XXX-01-X-D-XX-XX
06/08/1999
SHEET
1
OF
2
REVISION AE
POSITION 1
TAPE AND REEL PACKAGING VIEW
"B"
2.205 55.999
REF
"B"
.630 16.00
USER DIRECTION OF UN-REELING
POCKET NOT DETAILED
SECTION "B"-"B"
SCALE 1 : 1
[PARTS TO HAVE POSITION #1 LOADED
IN SAME DIRECTION AS ARROW]
TUBE PACKAGING VIEW
TUBE: PT-1-24-02-78
PLUG: TP-09
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 1.5:1
.5mm DOUBLE ROW SOCKET ASSEMBLY
BSH-XXX-01-X-D-XX-XX
06/08/1999
SHEET
2
OF
2
F:\DWG\MISC\MKTG\BSH-XXX-01-X-D-XX-XX-MKT.SLDDRW
BY:
DEAN P
