Datamate Connectors
Male Horizontal PC Tail
Jackscrews are assembled where specified.
For loose special contacts see pages 101-107.
Mates with connectors shown on pages 99 to 100.
NON-SYMMETRICAL CONTACT CONFIGURATION
2.50
5.55
5.60
4.50
Contact No. 1
2.00
0.50
4.00
2.00
3.00
Tail
Ø 0.5 0
EXAMPLE OF PART NUMBER
M80-5LX10XX-03-000
SYMMETRICAL CONTACT CONFIGURATION
3.00
Contact No. 1
SPECIAL CONTACTS ONLY
4.00
4.50
4.00
2.00
4.50
EXAMPLE OF PART NUMBER
M80-5LX06XX-22-000
EXAMPLE OF PART NUMBER
M80-5LX00XX-60-000
WITH JACKSCREWS
NO JACKSCREWS
WITH BOARD-MOUNT JACKSCREWS
M2
M2
M2
6.00
2.00
TAIL
BOLT
SERIES CODE
LENGTH LENGTH
3mm
3.5mm
5.0mm
3.5mm
5.0mm
M80-5L1XXM4
M80-5L1XXM5
M80-5L2XXM4
M80-5L2XXM5
TAIL LENGTH SERIES CODE
3mm
4.5mm
TAIL LENGTH
3mm
4.5mm
SERIES CODE
M80-5L1XX00
M80-5L2XX00
3mm
4.5mm
4.5mm
M80-5L1XXM1
M80-5L2XXM1
For special contacts (coaxial and power) please see page 101 to 107
www.harwin.com
97
DATAMATE
