1667 Overview

Female mini-plus cordset

Preview

Download Datasheet

View All

Connection Systems

Selection Guide

889N

Mini-Plus Style

Cordsets

889N

Mini-Plus Style

Patchcords

889N

Mini-Plus Style

Cordsets

889N

Mini-Plus Style

Patchcords

889N

Mini-Style

Cordsets

889N

Mini-Style

Cordsets

■

Female mini-plus

cordset

9, 10 and 12 pin

connector types

Straight and right angle

versions

Heavy duty STOOW-A

16 AWG cable

Oil resistant yellow

PVC jacket

Mates with main

connectors on

898-series distribution

boxes

600V

■

Male to female mini-

plus patchcord

9, 10, and 12-pin

connector types

Straight and right

angle versions

Heavy duty STOOW

16AWG or 18AWG cable

Oil resistant PVC jacket

Mates 898-series

distribution boxes to

1667-series

PanelConnect

■

Female mini-plus

cordset

7 and 8 pin

connector types

Straight female

connector

Heavy duty STOOW

16 AWG cable

Oil resistant yellow

PVC jacket

Mates with main

connectors on

898-series distribution

boxes

600V

■

Male to female mini-

plus patchcord

7 and 8-pin

connector types

Straight configuration

Heavy duty STOOW

16AWG cable

Oil resistant PVC jacket

Mates with main

connectors on

898-series distribution

boxes

■

Female mini

cordset

3, 4, 5 and 6 pin

connector types

Straight and right

angle versions

Heavy duty STOOW

16 AWG or standard

18 AWG cable

Oil resistant yellow

PVC jacket

Coiled cord available

■

Female illuminated

mini cordset

3 pin connector type

Right angle female

connector

300V 18 AWG cable

Oil resistant yellow

PVC jacket

Description

■

Features

■

16AWG: 600V

18AWG: 300V

Straight:

51mm x 32mm

Right angle:

56mm x 67mm

■

600V

■

16 AWG: 600V

18 AWG: 300V

Straight:

56mm x 25.4mm

Right angle:

40mm x 45mm

■

120V AC

Rated Voltage

Connector/

Body

Dimensions

Additional

Info

■

Straight:

51mm x 32mm

Right angle:

56mm x 67mm

■

56mm x 28mm

■

56mm x 28mm

■

40mm x 45mm

■

M115 catalog page 3-26

www.ab.com/catalogs

■

M115 catalog page 3-29

www.ab.com/catalogs

■

M115 catalog page 3-24

www.ab.com/catalogs

■

M115 catalog page 3-28

www.ab.com/catalogs

■

M115 catalog page 3-8

and 3-11

www.ab.com/catalogs

■

M115 catalog page 3-10

www.ab.com/catalogs

889N

Mini-Style

Male Cordsets

889N

Mini-Style

Patchcords

889D

DC Micro-Style

Cordsets

889D

DC Micro-Style

Cordsets

889D

DC Micro-Style

Male Cordsets

889D

DC Micro-Style

Patchcords

■

Male mini cordset

■

Male to female

mini patchcord

3, 4, 5, and 6 pin

connector types

Straight female

connector to straight or

right angle male

Heavy duty STOOW

16 AWG cable

Oil resistant yellow

PVC jacket

■

Female DC micro

cordset

4, 5, and 8 pin

connector types

Straight or right angle

versions

22 AWG or 18 AWG cable

Yellow or black cable

Standard or braided

versions

Multiple jacket types:

PVC, TPE, ToughLink,

ToughWeld

Coiled cord available

300V

■

Female illuminated

DC micro cordset

4 pin connector type

Straight and right angle

connectors

Standard 22 AWG

cable

PNP or NPN versions

Oil resistant yellow

PVC jacket

■

Male DC micro

cordset

4 and 5 pin connector

type

Straight and right angle

male connector

Standard 22 AWG cable

Yellow or black cable

Multiple jacket types:

PVC, TPE, ToughLink,

ToughWeld

■

Male to female DC

micro patchcord

4, 5, and 8 pin connector

types

Straight or right angle

female connector to

straight or right angle

male

22 AWG or 18 AWG cable

Yellow or black cable

Multiple jacket types:

PVC, TPE, ToughLink,

ToughWeld

300V

Description

■

3 and 4 pin connector

types

Straight male connector

Heavy duty STOOW

16 AWG cable

Oil resistant yellow PVC

jacket

■

Features

■

600V

■

600V

■

10-30V DC

■

300V

■

Rated Voltage

Connector/

Body

Dimensions

Additional

Info

■

49mm x 25.4mm

■

Straight:

49mm x 25.4mm

Right angle:

30mm x 42mm

■

Straight:

42mm x 15mm

Right angle:

27mm x 30mm

■

Straight:

42mm x 15mm

Right angle:

27mm x 30mm

■

Straight:

43mm x 15mm

Right angle:

43mm x 31mm

■

Straight:

43mm x 15mm

Right angle:

43mm x 31mm

■

M115 catalog page 3-12

www.ab.com/catalogs

■

M115 catalog page 3-13

www.ab.com/catalogs

■

This magazine page 70

M115 catalog page 3-36

www.ab.com/catalogs

■

M115 catalog page 3-40

www.ab.com/catalogs

■

This magazine page 70

M115 catalog page 3-45

www.ab.com/catalogs

■

This magazine page 70

M115 catalog page 3-46

www.ab.com/catalogs
