Coaxial
Power Splitter/Combiner
2 Way-0° Resistive 75Ω
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
0.75W max.
0.375W max.
ZFRSC-2075
DC to 2000 MHz
Features
• wideband, DC to 2000 MHz
• low insertion loss, 0.3 dB typ.
• excellent amplitude unbalance, 0.02 dB typ.
• rugged shielded case
CASE STYLE: K18
Connectors Model
BNC
ZFRSC-2075
BRACKET (OPTION "B")
Price
$59.95
$2.50
Qty.
(1-9)
(1+)
Permanent damage may occur if any of these limits are exceeded.
Applications
• laboratory
• test set-ups
FREQ.
RANGE
(MHz)
L
f
L
-f
U
Typ.
6.2
Coaxial Connections
SUM PORT
PORT 1
PORT 2
3
1
2
Electrical Specifications
ISOLATION
(dB)
M
Typ.
6.6
U
Typ.
7.0
INSERTION LOSS (dB)
ABOVE 6.0 dB
L
M
U
PHASE
UNBALANCE
(Degrees)
L
Max.
1
M
Max.
2
U
Max.
5
AMPLITUDE
UNBALANCE
(dB)
L
Max.
0.1
M
Max.
0.2
U
Max.
0.5
Typ. Max. Typ. Max. Typ. Max.
0.1
0.2
0.3
0.6
0.5
1.4
Outline Drawing
DC-2000
L = low range [DC-100 MHz]
M = mid range [100 MHz to f
U
/2]
U= upper range [f
U
/2 to f
U
]
This is a resistive power divider to enable frequency coverage from dc to the highest rated frequency. Since resistive power divider do not
provide a high degree of isolation (basically isolation equals the insertion loss between ports), an amplifier such as Mini-Circuits' ZFL
series is recommended when high isolation is required. Matched power rating 0.75W, internal load dissipation 0.375W.
Typical Performance Data
Frequency
(MHz)
Insertion Loss
(dB)
S-1
0.03
10.00
28.00
46.00
73.00
100.00
310.00
590.00
820.00
900.00
6.06
6.03
6.04
6.03
6.03
6.04
6.06
6.15
6.32
6.37
6.41
6.65
6.71
6.63
6.36
Amplitude
Unbalance
(dB)
0.00
0.00
0.01
0.01
0.00
0.01
0.00
0.01
0.01
0.03
0.01
0.01
0.01
0.00
0.01
Isolation
(dB)
Phase
Unbalance
(deg.)
0.01
0.01
0.05
0.03
0.03
0.02
0.11
0.14
0.36
0.39
0.46
0.53
0.70
0.71
0.65
VSWR
S
VSWR
1
VSWR
2
S-2
6.06
6.03
6.03
6.02
6.03
6.03
6.06
6.14
6.31
6.35
6.39
6.63
6.71
6.63
6.37
6.06
6.03
6.03
6.03
6.03
6.03
6.06
6.15
6.30
6.34
6.37
6.62
6.73
6.70
6.48
1.00
1.00
1.01
1.01
1.02
1.03
1.10
1.19
1.26
1.30
1.31
1.21
1.22
1.20
1.26
ZFRSC-2075
VSWR
1.00
1.00
1.01
1.01
1.02
1.03
1.11
1.21
1.28
1.32
1.34
1.24
1.24
1.21
1.25
1.00
1.00
1.01
1.01
1.02
1.03
1.10
1.20
1.27
1.30
1.32
1.23
1.22
1.19
1.22
Outline Dimensions (
inch
)
mm
A
1.25
31.75
J
--
--
B
1.25
31.75
K
--
--
C
.75
19.05
L
.125
3.18
D
.63
16.00
M
1.688
42.88
E
.38
9.65
N
2.18
55.37
F
1.00
25.40
P
.75
19.05
G
.125
3.18
H
1.000
25.40
Q
wt
.07 grams
1.78
70.0
980.00
1300.00
1500.00
1700.00
2000.00
ZFRSC-2075
INSERTION LOSS
7.0
INSERTION LOSS (dB)
S-1(dB)
S-2(dB)
1.5
#S-VSWR
#1-VSWR
#2-VSWR
6.8
6.6
6.4
6.2
6.0
0
400
800
1200
1600
2000
FREQUENCY (MHz)
1.4
VSWR
1.3
1.2
1.1
1.0
0
400
800
1200
1600
2000
FREQUENCY (MHz)
ZFRSC-2050
VSWR
1.20
#S-VSWR
#1-VSWR
#2-VSWR
1.15
VSWR
1.10
1.05
1.00
0
400
800
1200
1600
2000
FREQUENCY (MHz)
electrical schematic
Mini-Circuits
TM
®
minicircuits.com
REV. OR
M94666
ZFRSC-2075
HY/TD/CP
080310
ISO 9001 ISO 14001
AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
