STC8050SF
Absolute Maximum Ratings
Characteristic
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Emitter current
Collector power dissipation
Junction temperature
Storage temperature range
* : Package mounted on 99.5% Alumina 10×8×0.6mm
(Ta=25°C)
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
E
P
C*
T
J
T
stg
Rating
30
25
6
800
-800
350
150
-55~150
Unit
V
V
V
mA
mA
mW
°C
°C
Electrical Characteristics
Characteristic
Collector-emitter breakdown voltage
Collector cut-off current
Emitter cut-off current
DC current gain
Collector-emitter saturation voltage
Base-emitter voltage
Transition frequency
Collector output capacitance
(Ta=25°C)
Symbol
BV
CEO
I
CBO
I
EBO
h
FE*
V
CE(sat)
V
BE
f
T
C
ob
Test Condition
I
C
=1mA, I
B
=0
V
CB
=30V, I
E
=0
V
EB
=6V, I
C
=0
V
CE
=1V, I
C
=50mA
I
C
=500mA, I
B
=50mA
V
CE
=1V, I
C
=500mA
V
CE
=5V, I
C
=10mA
V
CB
=10V, I
E
=0
Min. Typ. Max.
25
-
-
85
-
-
-
-
-
-
-
-
-
0.85
180
19
-
50
50
300
0.5
1.2
-
-
Unit
V
nA
nA
-
V
V
MHz
pF
* : h
FE
Rank /
B : 85~160, C : 120~200, D : 160~300
KSD-T5C004-000
2
STC8050SF
