FV80524RX366128SL36C datasheet, PDF

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> FV80524RX366128SL36C

Preview

FV80524RX366128SL36C: DescriptionRISC Microprocessor, 32-Bit, 366MHz, CMOS, PPGA370; CategoryThe embedded processor and controller Microcontrollers and processors; File Size1MB，128 Pages; ManufacturerIntel; Websitehttp://www.intel.com/

Download Datasheet Parametric View All

FV80524RX366128SL36C Overview

RISC Microprocessor, 32-Bit, 366MHz, CMOS, PPGA370

FV80524RX366128SL36C Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
bit size	32
JESD-30 code	S-PPGA-P370
Number of terminals	370
Package body material	PLASTIC/EPOXY
encapsulated code	PGA
Encapsulate equivalent code	SPGA370,37X37
Package shape	SQUARE
Package form	GRID ARRAY
power supply	2 V
Certification status	Not Qualified
speed	366 MHz
Nominal supply voltage	2 V
surface mount	NO
technology	CMOS
Terminal form	PIN/PEG
Terminal pitch	1.27 mm
Terminal location	PERPENDICULAR
uPs/uCs/peripheral integrated circuit type	MICROPROCESSOR, RISC
Base Number Matches	1

Preview

Download Datasheet

View All

Intel

Celeron

Processor

up to 1.10 GHz

Datasheet

Available at 1.10 GHz, 1 GHz, 950 MHz,

900 MHz, 850 MHz, 800 MHz, 766 MHz,

733 MHz, 700 MHz, 667 MHz, 633 MHz,

600 MHz, 566 MHz, 533 MHz,

533A MHz, 500 MHz, 466 MHz,

433 MHz, 400 MHz, 366 MHz, 333 MHz,

and 300A MHz core frequencies with

128 KB level-two cache (on die); 300 MHz

and 266 MHz core frequencies without

level-two cache.

Intel’s latest Celeron

processors in the

FC-PGA/FC-PGA2 package are

manufactured using the advanced 0.18

micron technology.

Binary compatible with applications

running on previous members of the Intel

microprocessor line.

Dynamic execution microarchitecture.

Operates on a 100/66 MHz, transaction-

oriented system bus.

Specifically designed for uni-processor

based Value PC systems, with the

capabilities of MMX™ technology.

Power Management capabilities.

Optimized for 32-bit applications running

on advanced 32-bit operating systems.

Uses cost-effective packaging technology.

— Single Edge Processor (S.E.P.) Package

to maintain compatibility with SC242

(processor core frequencies (MHz):

266, 300, 300A, 333, 366, 400, 433).

— Plastic Pin Grid Array (PPGA) Package

(processor core frequencies (MHz):

300A, 333, 366, 400, 433, 466, 500,

533).

— Flip-Chip Pin Grid Array (FC-PGA /

FC-PGA2) Package (processor core

frequencies (MHz); 533A, 566, 600,

633, 667, 700, 733, 766, 800, 850, 900,

950); (GHz); 1, 1.10

Integrated high-performance 32 KB

instruction and data, nonblocking, level-

one cache: separate 16 KB instruction and

16 KB data caches.

Integrated thermal diode.

The Intel

Celeron

processor is designed for uni-processor based Value PC desktops and is

binary compatible with previous generation Intel architecture processors. The Celeron processor

provides good performance for applications running on advanced operating systems such as

Microsoft* Windows*98, Windows NT*, Windows* 2000, Windows XP* and Linux*. This is

achieved by integrating the best attributes of Intel processors—the dynamic execution

performance of the P6 microarchitecture plus the capabilities of MMX™ technology—bringing

a balanced level of performance to the Value PC market segment. The Celeron processor offers

the dependability you would expect from Intel at an exceptional value. Systems based on

Celeron processors also include the latest features to simplify system management and lower the

cost of ownership for small business and home environments.

FC-PGA2 Package

FC-PGA Package

PPGA Package

S.E.P. Package

Document Number:

243658-020

January 2002

Intel

Celeron

Processor up to 1.10 GHz
