MGDBI-04-I-F/M datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> MGDBI-04-I-F/M

MGDBI-04-I-F/M: DescriptionDC-DC Regulated Power Supply Module, 2 Output, 2W, Hybrid, ROHS COMPLIANT, MODULE-9/24; CategoryPower/power management The power supply circuit; File Size485KB，12 Pages; ManufacturerGAIA Converter Inc; Websitehttps://gaia-converter.com; Environmental Compliance

Download Datasheet Parametric Compare View All

MGDBI-04-I-F/M Overview

DC-DC Regulated Power Supply Module, 2 Output, 2W, Hybrid, ROHS COMPLIANT, MODULE-9/24

MGDBI-04-I-F/M Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Parts packaging code	MODULE
package instruction	ROHS COMPLIANT, MODULE-9/24
Contacts	9/24
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	-15V ADDITIONAL OUTPUT AVAILABLE
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	36 V
Minimum input voltage	18 V
Nominal input voltage	24 V
JESD-30 code	R-XDMA-P24
length	32 mm
Maximum load regulation	2%
Number of functions	1
Output times	2
Number of terminals	24
Maximum operating temperature	71 °C
Minimum operating temperature	-40 °C
Maximum output voltage	15.3 V
Minimum output voltage	14.7 V
Nominal output voltage	15 V
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum seat height	7.7 mm
surface mount	NO
technology	HYBRID
Temperature level	OTHER
Terminal form	PIN/PEG
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	2 W
Fine-tuning/adjustable output	NO
width	19.3 mm
Base Number Matches	1

Preview

Download Datasheet

View All

Industrial DC/DC CONVERTER

MGDI-04 Standard Input : 4W POWER

Industrial

Grade

2:1 Standard Input

Single & Bi Outputs

Metallic Case - 1 500 VDC Isolation

• Low profile : 0,3 “ ( 7.5mm)

• Nominal power of 4 W without derating

• Wide temperature range : -40°C/+95°C case

• High efficiency up to 80 %

• Soft start

• Galvanic isolation 1.500 VDC

• Integrated LC EMI filter

• Permanent short circuit protection

• Standard pin out DIL24 8 pins

• No optocoupler for high reliability

• RoHS process

1-General

The MGDI-04 series is a full family of DC/DC

power modules designed for use in distributed

power architecture and are particularly suitable

for mobile or ground fixed applications in

transportation, industry and telecommunications

areas. These modules use a high frequency fixed

switching technic at 480 KHz providing excellent

reliability, low noise characteristics, high power

density and a low profile package. Standard

models are available with nominal input volta-

ges as 5 or 24 volts in range of 4,5-5,5 or 18-36

volts. The series include single and bi output

voltage choices of 3,3, 5, 12, 15, +/-5, +/-12 or

+/-15 volts.

No external heatsink is required for the MGDI-

04 series to supply 4W output power over the

case temperature range of -40°C up to 95°C.

The MGDI-04 series is designed in conformity

with safety standards EN60950 and UL1950.

All the modules are designed with LC network

filters to minimize reflected input current ripple

and output voltage ripple according to EN55022

and FCC Part 15J standard.

The modules include a soft-start, a permanent

short circuit protection and an output overvoltage

protection to ensure efficient module protec-

tions. The soft-start allows current limitation and

eliminates inrush current during start-up. The

short circuit protection completely protects the

modules against short-circuits of any duration

by a shut-down and restores to normal when

the overload is removed.

The design has been carried out with surface

mount components and is manufactured in a

fully automated process to guarantee high

quality. Each module is tested and burned in

with a GAIA Converter automated test

equipment.

2-Product Selection

Single output model

Bi output model

: MGDSI - 04 -

: MGDBI - 04 -

input

output

Input Voltage Range

Permanent

C : 4,5-5,5 VDC

I : 18-36 VDC

Output

B : 3.3 VDC

C : 5 VDC or +/-5VDC

E : 12 VDC or +/-12VDC

F : 15 VDC or +/-15VDC

Options :

/M : option for On/Off function

REDEFINING THE SOURCE OF POWER

Gaia Converter FC97-004.01/11 Revision M

For locations, phone, fax, E-Mail see back cover
