DC BLOCKS
SMP 7 kHz - 26.5 GHz, Inner Only
,
SPECIFICATIONS:
Models: 8535PX, 8535PLX
Electrical:
Frequency Range
VSWR:
30 kHz - 1 GHz
2
1 GHz - 26.5 GHz
2
Impedance
Voltage Rating
Operating Temp Range
Rise Time (10 - 90%)
Insertion Loss
30 kHz - 26.5 GHz
7 kHz - 26.5 GHz
1.35:1 Max.
1.40:1 Max.
50 Ohms
50 Volts Max.
-35°C to +85°C
< 9 pS Typical
1.0 dB Max.
Typical performance from 7 kHz - 26.5 GHz
0
Insertion Loss (dB)
-0.2
-0.4
-0.6
-0.8
-1.0
-1.2
Mechanical:
SMP Connectors
Conductors
Barrel**
Gold Plated Beryllium Copper
Gold Plated Beryllium Copper
Passivated Stainless Steel
.000001
7 kHz
.0001
30 kHz
.001
.01
.1
1
10
100
FREQ (GHz)
26.5 GHz
3.0
2.8
2.6
2.4
** For a Gold Plated Barrel add /AU to the Model Number
GPO is a trademark of Corning Gilbert Inc.
VSWR
2.2
2.0
1.8
1.6
1.4
1.2
1.0
.000001
.0001
30 kHz
.001
.01
.1
1
10
100
Model Number:
8535PYZ
7 kHz
FREQ (GHz)
26.5 GHz
SMP Female
Connector
Configuration
Male/Female
Male/Male
Female/Female
Model
Numbers
8535P
8535PL
8535PM
8535PLM
8535PF
LENGTH
Inches
Millimeters
.58 ±.05
.56 ±.05
.60 ±.05
[1
4.73 ±1.27]
[1
4.22 ±1.27]
[15.24 ±1.27]
LENGTH
SMP Male
Ø.25 [6.35]
HOW TO ORDER:
Finish
= Passivated Barrel
/AU = Gold Plated Barrel
Model Number:
Ordering Examples:
Model Number:
8535P
SMP - Male/Female, Male has Full Detent Interface
Model Number:
8535PF
SMP- Female/Female
Model Number:
8535PLM
SMP - Male/Male, Limited Detent Interface
8535P: REV B
8535PYZ/FF
Connector Configuration
= Male/Female
F = Fem/Fem
M = Male/Male
Connector Style
= Full Detent Male Interface
L = Limited Detent Male Interface
Note: Dimensions in Brackets are Expressed in Millimeters and are for Reference Only.
Aeroflex / Inmet, Inc.
• 300 Dino Drive, Ann Arbor, MI 48103 • U.S.A.
888-244-6638 or 734-426-5553 • FAX: 734-426-5557
www.aeroflex.com/inmet • inmetsales@aeroflex.com
