Datasheet> All Categories > Analog mixed-signal IC> Trigger device> CTA30-400B

Preview

CTA30-400B: DescriptionTRIAC, 400V V(DRM), 30A I(T)RMS, TO-220AB, ISOLATED TO-220AB, 3 PIN; CategoryAnalog mixed-signal IC Trigger device; File Size852KB，2 Pages; ManufacturerCynergy 3; Environmental Compliance

Download Datasheet Parametric View All

CTA30-400B Overview

TRIAC, 400V V(DRM), 30A I(T)RMS, TO-220AB, ISOLATED TO-220AB, 3 PIN

CTA30-400B Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Parts packaging code	TO-220AB
package instruction	FLANGE MOUNT, R-PSFM-T3
Contacts	3
Reach Compliance Code	unknown
Other features	UL RECOGNIZED
Shell connection	ISOLATED
Configuration	SINGLE
Critical rise rate of commutation voltage - minimum value	10 V/us
Critical rise rate of minimum off-state voltage	500 V/us
Maximum DC gate trigger current	50 mA
Maximum DC gate trigger voltage	1.3 V
Maximum holding current	75 mA
JEDEC-95 code	TO-220AB
JESD-30 code	R-PSFM-T3
Maximum leakage current	0.005 mA
Number of components	1
Number of terminals	3
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum rms on-state current	30 A
Off-state repetitive peak voltage	400 V
surface mount	NO
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED
Trigger device type	TRIAC
Base Number Matches	1

Preview

Download Datasheet

View All

POWER COMPONENTS

Applications

•

Phase Control

•

Static Switching

•

Light Dimming

•

Motor Speed Control

•

Kitchen Equipment

•

Power Tools

•

Solenoid Valve Controls:

•

Dishwashers

•

Washing Machines

>

Suitable for General Purpose AC Switching

>

IGT 50mA

>

V

DRM

/V

RMM

400, 600, 800V

CTA30/CTB35

400/600/800V -

TRIAC

RATING

SYMBOL

IT

(RMS)

Absolute Maximum Ratings

RMS On-State Current (full sine wave)

Non Repetitive Surge Peak On-State Current

(Full Cycle, Tj Initial = 25

˚

C)

I

2

t Value for fusing

Critical rate of rise of on-state current

I

G

=2 x I

GT

, tr<100 ns, T

j

= 125

˚

C

Tc = 95˚C

Tc = 70˚C

CONDITIONS

TO-220AB

TO-220AB Iso

F =50 Hz

F =60 Hz

tp = 10 ms

35A (CTB)

30A (CTA)

335A

350A

500A

2

s

100A/µsec

4A

1W

-40 to +150

˚

C

-40 to +125

˚

C

2500 V

RMS

“B”

I

TSM

I

2

t

di/dt

A1

A2

Peak Gate Current @ T

j

= 125˚C

G

tp = 20 µs

Average Gate Power Dissipation @ Tj = 125

˚

C

Storage Temperature Range

A2

I

GM

P

G(AV

)

T

stg

T

j

V

ISO

TO-220AB Isolated

(CTA30)

Operating Junction Temperature Range

Isolation Voltage (CTA Series only)

Electrical Characteristics

A1

A2

STANDARD (4 Quadrants)

G

TO-220AB Non-Isolated

(CTB35)

I

GT

MAX @ V

D

=12 V, R

L

= 30Ω

I

GT

MAX @ V

D

=12 V, R

L

= 30Ω

NOTE 1

V

GT

MAX @ V

D

=12 V, R

L

= 30Ω

V

GD

MIN @ V

D

=V

DRM

, R

L

= 3.3kΩ

Tj = 125

˚

C

I

H

MAX @ I

T

= 500 mA

I

L

MAX @ I

G

= 1.2 I

GT

I

L

MAX @ I

G

= 1.2 I

GT

NOTE 2

NOTE 1

QI-II-III

QIV

Q-AII

QI-III-IV

Q-II

NOTE 2

50mA

100 mA

1.3V

0.2 V

75mA

100mA

500V/µsec

10V/µsec

A2

G

A1

dv/dt MIN @ V

D

= 67%V

DRM

(gate open)

(dv/dt)c MIN @ (di/dt)c = 13.3 A/ms

NOTE 2

Tj = 125˚C

Static Characteristics

V

T

MAX @ I

TM

=48 A, tp = 380µs

NOTE 2

Vto MAX @ Threshold Voltage

Rd MAX @ Dynamic Resistance

NOTE 2

I

DRM

MAX @ V

DRM =

V

RRM

NOTE 2

Tj = 25˚C

Tj = 125˚C

Tj = 25˚C

Tj = 125˚C

1.55 V

0.85 V

16 m

Ω

5µA

3 mA

ISO9001 Certified

I

RRM

MAX @ V

DRM =

V

RRM

GENERAL NOTES

1. Minimum IGT is guaranted at 5% of IGT max.

2. For both polarities of A2 referenced to A1

3. All parameters at 25 degrees C unless otherwise specified.
