Surge arrester
2-electrode arrester (twin)
Series/Type:
Ordering code:
Version/Date:
Version:
EG30-A90XSMD
B88069X9291T203
Issue 02 / 2010-09-16
01
Content of header bars 1 and 2 of data sheet will be automatically entered in headers and footers! Please fill in the
table and then change the color to "white" (or invisible). This ensures that the table disappears for the customer
PDF. To update the data sheet, click on the symbol "Preview" and then "Close". Please do not alter the header or
footer when copying the content.
Identification/Classification 1:
(header 1 + top left header bar)
Identification/Classification 2:
(header 2 + bottom left header bar)
Ordering code:
(top right header bar)
Series/Type:
(top right header bar)
Preliminary data (optional):
(if necessary)
Department:
Date:
PPD AB PD / PPD AB PM
Issue 02 / 2010-09-16
Surge arrester
2-electrode arrester (twin)
B88069X9291T203
EG30-A90XSMD
©
EPCOS AG 2010. Reproduction, publication and dissemination of this document, enclosures hereto and the information
contained therein without EPCOS' prior express consent is prohibited.
Surge arrester
2-electrode arrester (twin)
B88069X9291T203
EG30-A90XSMD
Features
Extremely small size
Very fast response time
Stable performance over life
Very low capacitance
High insulation resistance
Excellent SMD handling
RoHS-compatible
Electrical specifications
DC spark-over voltage
1) 2) 4)
Applications
ESD protection
Applications with limited space
90
±
30
< 500
< 350
< 700
< 600
100
2
20
>1
< 1.0
~ 10
~1
~ 60
~ 0.4
-40 ... +90
40/ 90/ 21
V
%
V
V
V
V
A
kA
A
GΩ
pF
V
A
V
g
°C
Impulse spark-over voltage
4)
at 100 V/µs - for 99 % of measured values
- typical values of distribution
at 1 kV/µs
- for 99 % of measured values
- typical values of distribution
8/20 µs
6)
8/20 µs
5)
10/1000 µs
5)
Service life
300 operations
(alternating polarity)
10 operations
[5× (+) & 5 x (–)]
300 operations
(alternating polarity)
Insulation resistance at 50 V
DC 4)
Capacitance at 1 MHz
4)
Arc voltage at 1 A
Glow to arc transition current
Glow voltage
Weight
Operation and storage temperature
Climatic category (IEC 60068-1)
Marking, without
1)
2)
3)
4)
5)
6)
At delivery AQL 0.65 level II, DIN ISO 2859
In ionized mode
Test according to ITU-T Rec. K.12
Tip or ring electrode to center electrodes
Total current through center electrodes, half value through tip respectively ring electrode.
Tip to ring electrode
Terms in accordance with ITU-T Rec. K.12 and DIN 57845/VDE0845
PPD AB PD / PPD AB PM
Please read
Cautions and warnings
and
Important notes
at the end of this document.
