NOD-5108: DescriptionBROADBAND NOISE INSTRUMENTS 10HZ TO 18GHZ; File Size723KB，1 Pages; ManufacturerMicronetics ( Mercury ); Websitehttp://www.micronetics.com/

Download Datasheet View All

NOD-5108 Overview

BROADBAND NOISE INSTRUMENTS 10HZ TO 18GHZ

Preview

Download Datasheet

View All

NOD 5000 S

ERIES

ROADBAND

OISE

NSTRUMENTS

10H

Z TO

18GH

Description

NOD Series Noise

Instruments are portable,

small and lightweight (less

than 10 lbs.) and designed to

provide accurate carrier-to-

noise measurements in the

lab, field or factory.

An attenuator is included

and calibrated at the connec-

tor, so there’s no need to

compensate for external con-

trol components.

Specifications

NOD S

ERIES

UTPUT

HARACTERISTICS

MODEL

NOD-2000

NOD-5101

NOD-5102

NOD-5103

NOD-5104

NOD-5105

NOD-5106

NOD-5107

NOD-5108

NOD-5109

NOD-5110

NOD-5111

NOD-5112

NOD-5124

NOD-5200

NOD-5250

NOD-5300

FREQUENCY

1.8GHz-2.2GHz

10Hz-20kHz

10Hz-100kHz

10Hz-500kHz

100Hz-3MHz

100Hz-10MHz

100Hz-25MHz

100Hz-100MHz

100Hz-300MHz

100Hz-500MHz

300MHz-1GHz

1GHz-2GHz

10MHz-2GHz

2GHz-4GHz

100Hz-1GHz

100Hz-1500MHz

2GHz-18GHz

FLATNESS

±0.5 dB

±0.75 dB

±1.0 dB

±1.25 dB

±1.5 dB

±2.0 dB

±2.5 dB

±3.0 dB

VSWR

2.0:1

1.5:1

2.0:1

2.2:1

2.5:1

RF OUTPUT POWER

(dBm/Hz) (dBm)

-77

-33

-40

-47

-55

-60

-64

-70

-75

-77

-79

-80

-83

-103

-80

-83

-112

+10

-10

+10

-10

Operating Temperature:

0 to +70 oC

Supply Voltage:

110 VAC/60 Hz or

220 VAC/50 Hz

Temperature Stability:

.025 dB/o C

Output Impedance:

50 ohm

Peak Factor: 5:1

Attenuation Range:

0 dB to 10 dB in 1 dB steps

or 0 dB to 100 dB in

10 dB steps

Dimensions:

9.38”W x 3.96”H x 10.75”D

Applications

Simulation of spread

spectrum signals (CDMA)

Carrier-to-noise

measurement

Bit error rate testing

Y Factor measurements

Modem testing

Optional 2nd & 3rd Rotary Attenuators available

Calibration Services offered

MICRONETICS / 26 HAMPSHIRE DRIVE / HUDSON, NH 03051 / TEL: 603-883-2900 / FAX: 603-882-8987

WEB: WWW.MICRONETICS.COM
