P10A05 THRU P10A10
Elektronische Bauelemente
VOLTAGE 50 ~ 1000 V
10 A, General Purpose Rectifiers
RoHS Compliant Product
A suffix of “-C” specifies halogen & lead-free
FEATURES
Low cost construction
Low forward voltage drop
Low reverse leakage
High forward surge current capability
High temperature soldering guaranteed:
250
o
C/10 second, at terminals
R -6
. 0 5 2 ( 1 .3 )
D IA
. 0 4 8 ( 1 .2 )
1 .0 ( 2 5 . 4 )
M IN .
.3 6 0 ( 9 . 1 )
.3 4 0 ( 8 . 6 )
.3 6 0 (9 .1 )
D IA
.3 4 0 (8 .6 )
MECHANICAL DATA
Case: transfer molded plastic
Polarity: Color band denotes cathode end
Mounting position: Any
Weight:
0.07ounces, 2.0 grams
1 .0 ( 2 5 . 4 )
M IN .
D im e n s io n s in in c h e s a n d ( m illim e te r s )
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating 25°C ambient temperature unless otherwise specified.
Single phase half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
TYPE NUMBER
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
@T
L
=75
℃
Peak Forward Surge Current 8.3ms single half
sine-wave superimposed on rated load
(JEDEC Method)
Maximum Instantaneous Forward Voltage Drop
per bridge element at 10A
Maximum DC Reverse Current at
rated DC blocking voltage
T
J
=25℃
T
J
=100℃
SYMBOLS P10A05
P10A1
P10A2
P10A4
P10A6
P10A8
P10A10
UNITS
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
C
J
T
J
T
STG
50
35
50
100
70
100
200
140
200
400
280
400
10.0
400
1.0
10
100
200
-65 to +175
-65 to +175
600
420
600
800
560
800
1000
700
1000
Volts
Volts
Volts
Amps
Amps
Volts
μA
pF
℃
℃
Typical Junction Capacitance (Note 2)
Operating and Storage Temperature Range
Storage Temperature Range
NOTES:
1. Measured at 1.0 MHz and applied reverse voltage of 4.0 Volts.
01-June-2002 Rev. A
Page 1 of 2
