ATTENUATORS
7/16 - DIN, up to 3 GHz, 100 Watts
SPECIFICATIONS:
Models: XD100W-XX, XD100W-XXF & XD100W-XXM
Electrical:
Frequency Range
Standard Freq. Values
Standard dB Values
Attenuation Accuracy
3 & 6 dB
10 dB
20 & 30 dB
40 dB
VSWR (Max.)
Input Power
Output Power
Peak Power
Impedance
Operating Temp Range
DC - 6.0 GHz
2.5 & 6 GHz
3, 6, 10, 20, 30 & 40 dB
1.5 - 2.5 GHz
2.5 - 6 GHz
±0.50 dB
±0.75 dB
±0.75 dB
±2.50 dB
±0.75 dB
±1.50 dB
±1.50 dB
±2.50 dB
1.35:1
1.45:1
100 Watts Avg. @ +25°C
o
DC - 1.5 GHz
±0.50 dB
±0.75 dB
±0.75 dB
±1.50 dB
1.25:1
Custom Mtg. hole Config.
may be Added to this
Surface
Derated Linearly to 20 Watts @ +125 C
3.46±.02
[87.88±0.51]
SQUARE
20 Watts
1 kW Max.
(5uSec Pulse, .05% Duty Cycle)
50 Ohms
-55°C to +125°C
Mechanical:
7/16 - DIN Connectors
Mates with DIN 47 223
END VIEW
TYPICAL
Units must be Mounted in such a way as to
Allow for Free Air Flow Around fins to Assure
Performance
Conductors
Housing
Silver Plated or White Bronze Alloy
Finished Brass
Silver or Gold Plated
Beryllium Copper or Brass
Anodized Aluminum
Note: Units are Unidirectional, Therefore Input Connector MUST be Specified & will be Indicated on Unit
Model Number:
XD100W-XX
Male/Female Connectors
Length: 7.41 ±.08 [188.2 ±2.0]
Pictured
7.41±.08
[188.24±2.03]
1.75 [44.45]
Model Number:
XD100W-XXF
Female/Female Connectors
Length: 7.55 ±.08 [191.8 ±2.0]
INPUT
Model Number:
XD100W-XXM
Male/Male Connectors
Length: 7.27 ±.08 [184.7 ±2.0]
.23 [5.84]
2X 8-32UNC-2B TAP
x .50 [12.7] DP.
2X M4x0.7 TAP
x .50 [12.7] DP.
HOW TO ORDER:
Model Number:
Ordering Examples:
Model Number:
2D100W-30
DC - 2.5 GHz, 30 dB; 7/16 - DIN, Male/Fem
Connector Configuration
= Male/Female
(Male Input)
F = Fem/Fem
M = Male/Male
FM = Female/Male
(Female Input)
Model Number:
2D100W-03F
DC - 2.5 GHz, 3 dB; 7/16 - DIN, Fem/Fem
Model Number:
6D100W-20FM
DC - 6 GHz, 20 dB; 7/16 - DIN, Female/Male
XD100W-XXY
Freq. Range
2 = DC - 2.5 GHz
6 = DC - 6 GHz
dB Value
Note: Dimensions in Brackets are Expressed in Millimeters and are for Reference Only.
Design specifications are subject to change without notice.
Contact factory for technical specifications before purchasing or use.
XD100W-ATT: REV K
Aeroflex / Inmet, Inc.
• 300 Dino Drive, Ann Arbor, MI 48103 • U.S.A.
888-244-6638 or 734-426-5553 • FAX: 734-426-5557
www.aeroflex-inmet.com • sales@aeroflex-inmet.com
