AC DC
60 Watts
SDS Series
•
•
•
•
•
•
•
xppower.com
Single, Dual, Triple & Quad Outputs
Output Voltages from 3.3 V to 48 V
Non standard Outputs Available
Industry Standard 3” x 5” Package
Fits 1U Applications
Open Frame, U Channel & Covered Versions
3 Year Warranty
Specification
Input
• 90-264 VAC (120-370 VDC)
• 47-63 Hz
• 1.6 A max at 115 VAC
1.0 A max at 230 VAC
Inrush Current
• <15 A at 115 VAC, cold start at 25 °C
<30 A at 230 VAC, cold start at 25 °C
Earth Leakage Current
• <0.30 mA at 115 VAC
<0.75 mA at 240 VAC
Power Factor
• EN61000-3-2, Class A
Input Protection
• T2 A/250 VAC internal fuse in line
Input Voltage
Input Frequency
Input Current
General
Efficiency
Isolation
• 80% typical, 230 VAC full load
• 3000 VAC Input to Output
1500 VAC Input to Ground
500 VDC Output to Ground
• 60 kHz typical
• 3.5 W/In
3
• Green DC OK LED
• 190 kHrs typical to MIL-HDBK-217F
at 25 °C, GB
Switching Frequency
Power Density
Signals
MTBF
Output
• See table
• ±10% on V1 only (see note 4)
• Single output models: ±1%
Multi-output models: ±5%
Minimum Load
• 10% required on V1 & V2 of multi-output
models to maintain regulation, unit will
start up with no load
Start Up Delay
• 2 s typical
Hold Up Time
• 12 ms min at 110 VAC, 100% load
Line Regulation
• 1% from low line to high line
Load Regulation
• 7% max all models 3% typical, see table
10% with no load on V1, for multi output
models
Transient Response
• 4% max deviation, recovery to within
1% in 4 ms for a 50% load change
Ripple & Noise
• 1% pk-pk typical, 20 MHz bandwidth
Overvoltage Protection
• 112-132% of nominal output voltage on
V1 only, recycle input to reset
Overload Protection
• 110-150% of nominal power,
with auto recovery
Short Circuit Protection
• Trip & restart (hiccup mode),
auto recovery
Temperature
• ±0.04%/°C
Coefficient
Output Voltage
Output Voltage Trim
Initial Set Accuracy
Environmental
Operating Temperature
• 0 °C to +70 °C, derate linearly from 100%
load at +50 °C to 50% load at +70 °C
• Convection-cooled
Cooling
Operating Humidity
• 5-95% RH, non-condensing
Storage Temperature
• -40 °C to +85 °C
EMC & Safety
Emissions
Harmonic Currents
Voltage Flicker
ESD Immunity
Radiated Immunity
EFT/Burst
Surge
Conducted Immunity
Magnetic Field
Dips & Interruptions
•
•
•
•
•
•
•
•
•
•
EN55022, level B conducted and radiated
EN61000-3-2, Class A
EN61000-3-3
EN61000-4-2, level 2 contact, level 3 air,
Perf Criteria A
EN61000-4-3, level 2, Perf Criteria A
EN61000-4-4, level 2, Perf Criteria A
EN61000-4-5, installation Class 3,
Perf Criteria A
EN61000-4-6, level 2, Perf Criteria A
EN61000-4-8, 1 A/m, Perf Criteria A
EN61000-4-11, 30% 10 ms,
60% 100 ms, 100% 5000 ms
Perf Criteria A, B, B
EN60950-1, UL60950-1,
CSA60950-1 per cUL
Safety Approvals
•
AC DC
Models and Ratings
Output Power
50 W
55 W
60 W
63 W
63 W
63 W
63 W
63 W
63 W
63 W
63 W
Output Power
63.0 W
48.1 W
63.0
63.0
63.0
53.5
53.5
63.0
63.0
63.0
63.0
63.0
63.0
63.0
63.0
63.0
63.0
63.0
63.0
59.3
W
W
W
W
W
W
W
W
W
W
W
W
W
W
W
W
W
W
Output Voltage
3.3
5.0
7.0
9.0
12.0
15.0
19.0
24.0
30.0
36.0
48.0
V
V
V
V
V
V
V
V
V
V
V
Output Current
15.1
11.0
8.6
7.0
5.2
4.2
3.3
2.6
2.1
1.7
1.3
A
A
A
A
A
A
A
A
A
A
A
Factory-Set
Voltage Range
(1)
3.0-5.0
5.0-6.0
6.0-8.0
8.0-11.0
11.0-13.0
13.0-16.0
16.0-21.0
21.0-27.0
27.0-33.0
33.0-40.0
40.0-50.0
VDC
VDC
VDC
VDC
VDC
VDC
VDC
VDC
VDC
VDC
VDC
Current Range
16.6-10.0
11.0-9.1
10.0-7.5
7.8-5.7
5.7-4.8
4.8-3.9
3.9-3.0
3.0-2.3
2.3-1.9
1.9-1.5
1.5-1.2
A
A
A
A
A
A
A
A
A
A
A
Total Regulation
5%
5%
4%
3%
3%
3%
3%
2%
2%
2%
2%
Output V4
(3)
SDS60
Model Number
(5,6)
SDS60US03
SDS60US05
SDS60US07
SDS60US09
SDS60US12
SDS60US15
SDS60US19
SDS60US24
SDS60US30
SDS60US36
SDS60US48
Model Number
(5,6)
SDS60UD01
SDS60UD04
-12.0
-5.0
+5.0
+12.0
-12.0
-12.0
-5.0
-15.0
-24.0
-12.0
+12.0
-12.0
-12.0
-12.0
-12.0
-12.0
-15.0
-15.0
V/0.8
V/0.8
V/0.8
V/1.0
V/1.0
V/0.8
V/0.8
V/0.8
V/0.5
V/0.8
V/0.8
V/0.8
V/0.8
V/0.8
V/0.8
V/0.8
V/0.8
V/0.1
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
-5.0
+5.0
-5.0
+24.0
-24.0
-5.0
+12.0
V/0.8
V/0.8
V/0.8
V/0.8
V/0.8
V/0.8
V/0.8
A
A
A
A
A
A
A
SDS60UT00
SDS60UT01
SDS60UT02
SDS60UT03
SDS60UT04
SDS60UT05
SDS60UT06
SDS60UT07
SDS60UT08
SDS60UT09
SDS60UT10
SDS60UQ00
SDS60UQ01
SDS60UQ02
SDS60UQ03
SDS60UQ04
SDS60UQ05
SDS60UQ06
Output V1
(2,3,4)
+5.0 V/7.0 A
+3.3 V/7.0 A
+3.3
+3.3
+3.3
+3.3
+3.3
+5.0
+5.0
+5.0
+5.0
+5.0
+5.0
+3.3
+3.3
+5.0
+5.0
+5.0
+5.0
+5.0
V/6.0
V/6.0
V/6.0
V/5.0
V/5.0
V/6.0
V/6.0
V/6.0
V/6.0
V/6.0
V/6.0
V/6.0
V/6.0
V/6.0
V/6.0
V/6.0
V/6.0
V/6.0
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
Output V2
(2,3,4)
+12.0 V/3.0 A
+5.0 V/5.0 A
+12.0
+12.0
+12.0
+5.0
+5.0
+12.0
+12.0
+15.0
+24.0
+24.0
+24.0
+12.0
+12.0
+12.0
+12.0
+12.0
+15.0
+24.0
V/3.0
V/3.0
V/3.0
V/5.0
V/5.0
V/3.0
V/3.0
V/3.0
V/2.0
V/2.0
V/2.0
V/3.0
V/3.0
V/3.0
V/3.0
V/3.0
V/3.0
V/1.8
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
Output V3
(3)
Notes
1. If an output voltage within the factory-set voltage range is required, a model
number will be allocated at the time of order.
2. 10% minimum load required on V1 & V2 of multi-output units to maintain
regulation of ±5%. Regulation increases to ±10% with no load.
3. Other output combinations are available - contact sales for more information.
4. On multi-output units V2 tracks V1, if V1 is adjusted by 5%, V2 changes by 5%.
5. For optional U-bracket, add suffix ‘B’ to model number.
6. For optional 2 pin AC input, contact sales for details.
7. To receive unit with cover fitted, add suffix ‘-C’ to model number.
Mechanical Details
0.16 (4.0) DIA MOUNTING HOLE (4PL.)
0.22 (5.6)
ADJ
DC OK
LED
2.55 (64.8)
3.00 (76.2)
1
P2
DC
OUTPUT
6
(multi output only) 7
8
AC
INPUT
P1
L
N
G
Pin
1
2
3
4
5
6
7
8
Single Output
Output 1
Output 1
Output 1
Return
Return
Return
PIN CONNECTIONS
Dual Output
Triple Output
Output 2
Output 2
Output 1
Output 1
Output 1
Output 1
Common
Common
Common
Common
N/C
Output 3
Quad Output
Output 2
Output 1
Output 1
Common
Common
Output 3
Output 4
Output 4
Notes
1. All dimensions are in inches (mm)
2. Weight: 0.52 lbs (240 g) approx
3. Tolerance: ±0.02 (0.5)
4. Input connector mates with Molex housing 09-50-3051 and Molex 2878 series crimp terminal.
5. Output connector mates with Molex housing 09-50-3061 or 9-50-3081 and
Molex 2878 series crimp terminal.
6. For optional cover kit order part number SDS60 COVER KIT, to receive unit with cover
fitted add suffix ‘-C’ to model number. Cover size: 5.46 x 3.55 x 1.55 (140 x 91 x 39.7mm).
7. For mating connectors and cable harness order part numbers:
SDS60 CON KIT
- Single, dual and triple output models
SDS60Q CON KIT
- Quad output models
SDS60 LOOM KIT
- Single output models cable harness
SDS60DT LOOM KT
- Dual and triple output models cable harness
SDS60Q LOOM KIT
- Quad output models cable harness
4.56 (115.8)
5.00 (127.0)
0.22 (5.6)
0.12 (3.0)
max
1.20 (30.5)
