82
INDIRECT FREQUENCY SYNTHESIZERS
60-000 Series
Series 60-000 Frequency Synthesizers are designed for
use in general purpose RF signal applications where
quick delivery is required.
ELECTRICAL SPECIFICATIONS
Frequency Range:
Operating Bandwidth:
Output Power:
Frequency Stability:
Input Reference:
Note 1
Frequency –
Power –
SYNTHESIZERS
ENVIRONMENTAL SPECIFICATIONS
0.4 to 4.95 GHz
See Table 1
+ 8 dBm, minimum
Same as Ref. input
10 to 100 MHz
+ 3 to + 9 dBm
(Sine or TTL, 50 ohm)
200 kHz to 50 MHz
See Table II
See Figure 1
2.0:1, typical
- 15 dBc, maximum
See Table II
+ 14 to 18 volts
See Table I
Phase Lock (“0” = lock)
Parallel, TTL
Standard Operating Temperature:
(See Option - 002 for - 54 to + 85 °C.)
0 to + 70 °C
MECHANICAL SPECIFICATIONS
Size:
RF Connectors:
See Outline
SMA or GPO
OPTION
- 002 Extended Operating Temperature:
- 54 to + 85 °C
Step Size:
Switching Speed:
Phase Noise:
Output VSWR:
Harmonics:
Spurious:
Power Supply:
DC Current:
BITE Scheme:
Digital Control:
Typical Phase Noise @ 1.0 GHz
200 kHz Step
-50
10 MHz Step
SSB Level (dBc/Hz)
-70
-90
-110
-130
-150
-170
1
5
10
100
1000
Offset Frequency (kHz)
Figure 1
10000
Note 1: K is a ratio of the input reference signal divided by the selected step size as defined below:
Group A: K = Ref. Signal
Step Size
Group B: K =
1
⁄
2
[Ref. Signal/Step Size)
Group C: K =
1
⁄
4
[Ref. Signal/Step Size)
K must be an even divisible and be a number over the range of 1 to 1023. The output noise will degrade if K
≤
10.
Specifications are subject to change without notice.
ABC
4726 Eisenhower Blvd • Tampa, Florida 33634-6391
Telephone: +1 813-884-1411 • Fax: +1 813-886-2794 • http://www.trak.com
INDIRECT FREQUENCY SYNTHESIZERS
83
TABLE I – MODEL NUMBER SELECTION GUIDE
Frequency Range
(GHz)
Model Number
Current
(mA, maximum)
Group
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Description
BIT 1
BIT 2
BIT 3
BIT 4
BIT 8
No Connection
BIT 10
No Connection
No Connection
No Connection
BIT 12
+ 15 Vdc
Ground
BIT 0
LOCK (Logic 0 = Lock)
BIT 5
BIT 6
BIT 7
BIT 9
BIT 11
BIT 13
SYNTHESIZERS
0.4 to .6
.6 to .9
.9 to 1.25
1.25 to 1.6
1.6 to 2.1
2.1 to 2.5
2.2 to 2.8
2.7 to 3.25
3.1 to 3.75
3.75 to 4.35
4.35 to 4.95
60-000-9X00-000
60-000-9X01-000
60-000-9X02-000
60-000-9X03-000
60-000-9X04-000
60-000-9X06-000
60-000-9X07-000
60-000-9X08-000
60-000-9X09-000
60-000-9X10-000
60-000-9X11-000
320
320
320
320
340
340
380
380
380
380
380
A
A
A
A
B
B
C
C
C
C
C
TABLE II – STEP SIZE DESIGNATOR
Step Size
(MHz)
Switching Speed
(µs, maximum)
Group A
Group B
Group C
Spurious
Designator
(dBc, maximum) Number
.2
.5
1
2
5
10
20
50
1200
600
300
150
100
50
25
25
2400
1200
600
300
200
100
50
50
4800
2400
1200
600
400
200
100
100
- 55
- 55
- 55
- 60
- 60
- 60
- 65
- 65
2X.125
1
2
3
4
5
6
7
8
2X 1.250
+.005
4XO .104 -.002 THRU
RF OUT
4X.15
J2
SYNTHESIZER
P/N
S/N
MFG DATE
2.400±.005
2X 2.150
.82
MDM 21 SOCKET
MATES WITH
MDM 21P
0
2X .125
.460 MAX
8X.32
.25
J1
4X.25
4X.25
2X.74
REF IN
1.500±.005
Ordering Information:
Specify the Model Number from Table I by replacing the “X” with the desired step size designation number from Table II.
Designate extended operating temperature option by changing the last three digits of the model number from -000 to -002.
Example:
Model 60-000-9100-002 is a .4 to .6 GHz synthesizer with 0.2 MHz step size and extended operating temperature option.
ABC
4726 Eisenhower Blvd • Tampa, Florida 33634-6391
Telephone: +1 813-884-1411 • Fax: +1 813-886-2794 • http://www.trak.com
