BC868-10/16/25
0.5W
NPN Medium
Power Transistors
•
•
•
•
•
•
Features
Halogen
free available upon request by adding suffix "-HF"
High current
Low voltage
Lead Free Finish/RoHS Compliant ("P" Suffix designates
RoHS Compliant. See ordering information)
Epoxy meets UL 94 V-0 flammability rating
Moisure Sensitivity Level 1
Electrical Characteristics @ 25
O
C Unless Otherwise Specified
Symbol
Parameter
Collector-Base Breakdown Voltage
(I
C
=100uAdc, I
E
=0)
Collector-Emitter Breakdown Voltage
(I
C
=1mAdc, I
B
=0)
Emitter-Base Breakdown Voltage
(I
E
=100uAdc, I
C
=0)
Collector Cutoff Current
(V
CB
=25c, I
E
=0)
Emitter Cutoff Current
(V
EB
=5.0Vdc, I
C
=0)
DC Current Gain
(I
C
=50mAdc, V
CE
=1.0Vdc)
DC Current Gain
(I
C
=1Adc, V
CE
=1.0Vdc)
DC Current Gain
(I
C
=5mAdc , V
CE
=10Vdc)
Collector-Emitter Saturation Voltage
(I
C
=1Adc, I
B
=100mAdc)
Base-Emitter On Voltage(1)
( I
C
=5mAdc, V
CE
=10Vdc )
Base-Emitter On Voltage(2)
( I
C
=1dc, V
CE
=1Vdc )
Transition Frequency
(I
C
=10mAdc, V
CE
=5Vdc, f=100MHZ)
Min
32
20
5.0
---
---
Max
---
---
---
0.1
0.1
Units
Vdc
Vdc
Vdc
uAdc
uAdc
SOT-89
A
B
K
OFF CHARACTERISTICS
V
(BR)CBO
V
(BR)CEO
V
(BR)EBO
I
CBO
I
EBO
E
C
D
G
H
J
F
ON CHARACTERISTICS
h
FE(1)
h
FE(2)
h
FE(3
V
CE(sat)
V
BE(on)
V
BE(on)
85
60
50
---
---
---
375
---
---
0.5
0.62
(Typ)
1
---
---
---
Vdc
Vdc
Vdc
1
2
3
1.
BASE
2.
COLLECTOR
3.
EMITTER
SMALL-SIGNAL CHARACTERISTICS
f
T
40
---
MHz
CLASSIFICATION OF H
FE (1)
Rank
Range
Marking
BC868-10
85-160
CBC
BC868-16
120-200
CCC
BC868-25
160-375
CDC
1.55
.061
25
REF.
www.mccsemi.com
Revision:
B
1 of 3
2013/01/01
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-TP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-TP-HF
Packing
Tape&Reel;1Kpcs/Reel
