American Opto Plus LED
C/A1021X
Single Digit Numeric Display
PACKAGE DIMENSIONS
MAIN FEATURES:
♦
♦
♦
♦
1.02 INCH (26mm) DIGIT HEIGHT
WIDE VIEWING ANGLE
EXCELLENT CHARACTER APPEARANCE
CASE MOLD TYPE
◆
SELECTION GUIDE AND APPLICATION INFORMATION ( RATINGS AT 25
℃
AMBIENT )
Chip
Part No.
Raw
Material
Emitted
Color
C/A1021E
C/A1021G
C/A1021Y
GaAsP/GaP
GaP
GaAsP/GaP
H. E. Red
Green
Yellow
Electro-Optical Characteristics
If
If
Vf (V)
If
Iv (mcd)
λ
Pd
λ
p (nm)
nm MW mA (Peak) Min
Typ.
Max.
(Rec) Min.
Typ.
(dp/2)
.
(dp)
(dp)
Common Cathode
635
45 100
30
160 3.4 4.0 (2.0)
5.6 (2.8) 10-20
2
4.5
Common Cathode
Common Cathode
C.C
or
CA
Wave
Length
Absolute Maximum Ratings
565
585
30
30
100
100
30
30
160
160
3.4
3.4
4.2 (2.1)
4.2 (2.1)
5.6 (2.8)
5.6 (2.8)
10-20
10-20
10-20
1.5
1.4
-
4
3.5
32
GaAlAs
Super Red Common Cathode
C/A1021SR
660
20 150
30
200
-
3.6 (1.8)
5.0 (2.5)
Please indicate Surface color and Segment Color when placing order or requesting samples.
For example : C1021SR GW is Grey surface and white segment. C1021SR BW is Black surface and white segment
◆
ABSOLUTE MAXIMUM RATING: (Ta=25°C )
Reverse Voltage
Reverse Current (Vr=5V)
Operating Temperature Range
Storage Temperature Range
Soldering Temperature
Preheating Temperature
: 5 Volt
: 100
μ
A
: -25°C ~ +85°C
: -25°C ~ +85°C
: 240 ~ 250 for 3seconds.
: 100 ~ 150 for 2 minutes.
Para meter Description
Spectral Line half-width
Power dissipation
Peak Forward Current (Duty 1/10,0.1ms pulse width)
Recommended Operation Current
Average Luminous intensity (If=10Ma)
Symbol
Unit
nm
mW
mA
mA
μcd
λ
Pd
If (Peak)
If (Rec)
Iv
