7.5mm BI-COLOR BIG LED LAMP
Features
7.5mm DIAMETER BIG LAMP
SUPER BRIGHT VERSION.
3 LEADS, COMMON ANODE.
I.C. COMPATIBLE.
THIRD COLOR (MIXED COLOR) AVAILABLE.
RELIABLE AND RUGGED.
LONG LIFE - SOLID STATE RELIABILITY.
L1799SRSRC/CA
SUPER BRIGHT RED / SUPER BRIGHT RED
Package Dimensions
Description
The Super Bright Red source color devices are made with
Gallium Aluminum Arsenide Red Light Emitting Diode.
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subjected to change without notice.
Selection Guide
Iv (mc d )
@ 20 mA
Min .
SUPER BRIGHT RED (GaAlAs)
L1799SRSRC/CA
SUPER BRIGHT RED (GaAlAs)
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Par t No .
Di c e
L en s Ty p e
View in g
An g l e
2θ1/2
Ty p .
600
480
WATER CLEAR
480
40°
600
SPEC NO: DSAA0298
REV NO: V.1
DATE: MAR/15/2001
PAGE: 1 OF 3
Electrical / Optical Characteristics at T
)
=25°C
°
Sy m b o l
λ
peak
∆λ
1/2
C
V
F
I
R
Par ameter
Peak Wavelength
Spectral Line Halfwidth
Capacitance
Forward Voltage
Reverse Current
Dev ic e
Super Bright Red
Super Bright Red
Super Bright Red
Super Bright Red
All
Ty p .
660
20
95
1.85
2.5
10
Max .
Un i t s
nm
nm
pF
V
uA
Tes t Co n d itio n s
IF=20mA
IF=20mA
VF=0V;f=1MHz
IF=20mA
VR = 5V
Absolute Maximum Ratings at T
)
=25°C
°
Par ameter
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Soldering Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
Su p er B r ig h t Red
100
30
150
5
-40
°
C To +85
°C
260
°
C For 5 Seconds
Un i t s
mW
mA
mA
V
SPEC NO: DSAA0298
REV NO: V.1
DATE: MAR/15/2001
PAGE: 2 OF 3
