Terminals
®
Nylon Insulated Pin Terminals
Catalog
Number
KN18-12PT-M
KN14-12PT-M
KN10-14PT-D
®
Wire
Range
22-16 A.W.G.
0.5-1.5 mm
2
Dimension
inch
mm
W
.075
1.9
.075
1.9
.110
2.8
F
.472
12.0
.472
12.0
.551
14.0
L
.898
22.8
.898
22.8
1.063
27.0
E
.433
11.0
.433
11.0
.512
13.0
D
.177
4.5
.205
5.2
.276
7.0
d1
.067
1.7
.091
2.3
.134
3.4
T
.030
0.75
.031
0.8
.039
1.0
16-14 A.W.G.
1.5-2.5 mm
2
12-10 A.W.G.
4-6 mm
2
• For Use in Pin-Style
Terminal Blocks
• Metal Insulation Sleeve
• Molded Insulator
• Internal Barrel Serrations
• Funnel Entry
Box Quantity: (D)=500; (M)=1000
For Mylar Tape replace box quantity with (T). Example: KN18-12PT-T
UL File #E9809
CSA File #LR4503
See pages in back of catalog for complete tool information.
Tool and Die Selection Chart on page M42.
Maximum Electrical Rating:
105˚C 600 Volts Max.
Terminal Material:
Copper
Vinyl Insulated Pin Terminals
Catalog
Number
KV18-12PT-M
KV14-12PT-M
KV10-14PT-D
®
®
Wire
Range
22-16 A.W.G.
0.5-2.5 mm
2
Dimension
inch
mm
W
.075
1.9
.075
1.9
.110
2.8
F
.472
12.0
.472
12.0
.551
14.0
L
.898
22.8
.898
22.8
1.063
27.0
E
.433
11.0
.433
11.0
.512
13.0
D
.157
4.0
.177
4.5
.252
6.4
d1
.067
1.7
.091
2.3
.134
3.4
T
.030
0.75
.031
0.8
.039
1.0
16-14 A.W.G.
1.5-2.5 mm
2
12-10 A.W.G.
4-6 mm
2
M
Spec-Kon
• For Use in Pin-Style
Terminal Blocks
• Molded Funnel Entry Insulator
• Brazed Seams
• Internal Barrel Serrations
Box Quantity: (D)=500; (M)=1000
For Mylar Tape replace box quantity with (T). Example: KV18-12PT-T
UL File #E9809
CSA File #LR4503
See pages in back of catalog for complete tool information.
Tool and Die Selection Chart on page M42.
®
Maximum Electrical Rating:
105˚C 600 Volts Max.
Terminal Material:
Copper
Tools used with Nylon and Vinyl Insulated Pin Terminals
ERG2500
KT-2500
© 2002 Thomas & Betts Corporation. Specifications are subject to change without notice.
www.tnb.com
M21
