PCI-1758UDI
PCI-1758UDO
Features
128-ch Isolated Digital Input
Universal PCI Card
128-ch Isolated Digital Output
Universal PCI Card
PCI-1758UDO
128 isolated digital output channels
High-voltage isolation on output channels (2,500 V
DC
)
Wide output range (5 ~ 40 V
DC
)
High-sink current for isolated output channels (90 mA max./channel)
Current protection for each port
BoardID™ switch
Output status read-back
Digital output value retained after hot system reset
Programmable Power-up States
Watchdog timer
PCI-1758UDI
128 isolated digital input channels
Wide input range (5 ~ 25 V
DC
)
High ESD protection (2,000 V
DC
)
Digital Filter function
BoardID™ switch
Interrupt handling capability for each channel
RoHS
2002/95/EC
PCI-1758UDI
PCI-1758UDO
COMPLIANT
Specifications
Isolated Digital Input
Channels
Input Voltage
PCI-1758UDI: 128
Logic 0: 2.5 V max.
Logic 1: 5 V min. (25 V max.)
Interrupt Capable Ch.
PCI-1758UDI: 128
Isolation Protection
2,500 V
DC
Opto-Isolator Response
20 µs
Input Resistance
3 kW
Feature Details
Interrupt Function (PCI-1758UDI)
PCI-1758UDI provides an interrupt function for every digital input channel. You can
disable/enable the interrupt functions, and select trigger type by setting the Rising Edge
Interrupt Registers or Falling Edge Interrupt Registers of the card. When the interrupt
request signals occur, software will service these interrupt requests by ISR. The multiple
interrupt sources provide the card with more flexibility.
Digital Filter Function (PCI-1758UDI)
The digital filter function is used to eliminate glitches on input data and reduce the
number of changes to examine and process. The filter blocks pulses that are shorter than
the specified timing interval and passes pulses that are twice as long as the specified
interval. Intermediate-length pulses that are longer than half of the interval, but less than
the interval, may or may not pass the filter depending on your settings.
Isolated Digital Output
Channels
Output Type
Isolation Protection
Output Voltage
Sink Current
Opto-isolator Response
PCI-1758UDO: 128
Sink (NPN)
2,500 V
DC
5 ~ 40 V
DC
90 mA max./channel
20 µs
Pin Assignments
CNB
PEF_COMM
PEF_COMM
PF_IDI07
PF_IDI06
PF_IDI05
PF_IDI04
PF_IDI03
PF_IDI02
PF_IDI01
PF_IDI00
PE_IDI07
PE_IDI06
PE_IDI05
PE_IDI04
PE_IDI03
PE_IDI02
PE_IDI01
PE_IDI00
NC
NC
NC
NC
NC
NC
NC
NC
PCD_COMM
PCD_COMM
PD_IDI07
PD_IDI06
PD_IDI05
PD_IDI04
PD_IDI03
PD_IDI02
PD_IDI01
PD_IDI00
PC_IDI07
PC_IDI06
PC_IDI05
PC_IDI04
PC_IDI03
PC_IDI02
PC_IDI01
PC_IDI00
NC
NC
NC
NC
NC
NC
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
80
79
78
77
76
75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
PAB_COMM
PAB_COMM
PB_IDI07
PB_IDI06
PB_IDI05
PB_IDI04
PB_IDI03
PB_IDI02
PB_IDI01
PB_IDI00
PA_IDI07
PA_IDI06
PA_IDI05
PA_IDI04
PA_IDI03
PA_IDI02
PA_IDI01
PA_IDI00
NC
NC
NC
NC
NC
NC
NC
NC
P89_COMM
P89_COMM
P9_IDI07
P9_IDI06
P9_IDI05
P9_IDI04
P9_IDI03
P9_IDI02
P9_IDI01
P9_IDI00
P8_IDI07
P8_IDI06
P8_IDI05
P8_IDI04
P8_IDI03
P8_IDI02
P8_IDI01
P8_IDI00
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
P0_IDI00
P0_IDI01
P0_IDI02
P0_IDI03
P0_IDI04
P0_IDI05
P0_IDI06
P0_IDI07
P1_IDI00
P1_IDI01
P1_IDI02
P1_IDI03
P1_IDI04
P1_IDI05
P1_IDI06
P1_IDI07
P01_COMM
P01_COMM
NC
NC
NC
NC
NC
NC
NC
NC
P2_IDI00
P2_IDI01
P2_IDI02
P2_IDI03
P2_IDI04
P2_IDI05
P2_IDI06
P2_IDI07
P3_IDI00
P3_IDI01
P3_IDI02
P3_IDI03
P3_IDI04
P3_IDI05
P3_IDI06
P3_IDI07
P23_COMM
P23_COMM
CNA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
NC
NC
NC
NC
NC
NC
P4_IDI00
P4_IDI01
P4_IDI02
P4_IDI03
P4_IDI04
P4_IDI05
P4_IDI06
P4_IDI07
P5_IDI00
P5_IDI01
P5_IDI02
P5_IDI03
P5_IDI04
P5_IDI05
P5_IDI06
P5_IDI07
P45_COMM
P45_COMM
NC
NC
NC
NC
NC
NC
NC
NC
P6_IDI00
P6_IDI01
P6_IDI02
P6_IDI03
P6_IDI04
P6_IDI05
P6_IDI06
P6_IDI07
P7_IDI00
P7_IDI01
P7_IDI02
P7_IDI03
P7_IDI04
P7_IDI05
P7_IDI06
P7_IDI07
P67_COMM
P67_COMM
General
Bus Type
I/O Connectors
Dimensions (L x H)
Power Consumption
Typical
Max.
Universal PCI V2.2
1 x MINI-SCSI HDRA-E100 female connector
175 x 100 mm (6.9" x 3.9")
PCI-1758UDI
+5 V @ 0.3 A
+5 V @ 0.6 A
PCI-1758UDO
+5 V @ 1.1 A
+5 V @ 2.2 A
Operating Temperature
0 ~ 60° C (32 ~ 140° F) (IEC 68-2-1, 2)
Storage Temperature
-20 ~ 70° C (-4 ~ 158° F)
Storage Humidity
5 ~ 95 % (IEC 68-2-3) non-condensing
Ordering Information
PCI-1758UDI
PCI-1758UDO
PCL-101100S-1
PCL-101100S-2
ADAM-39100
128-ch Isolated DI Universal PCI Card
128-ch Isolated DO Universal PCI Card
100-pin SCSI Cable, 1 m
100-pin SCSI Cable, 2 m
100-pin DIN-rail SCSI Wiring Board
PCI-1758UDI
Online Download
www.advantech.com/products
