PSB1SJDA481000: DescriptionSingle Phase Solid State Relays; File Size122KB，2 Pages; ManufacturerPowersem GmbH; Websitehttps://www.powersem.net/index.php

Download Datasheet Compare View All

PSB1SJDA481000 Overview

Single Phase Solid State Relays

Preview

Download Datasheet

View All

Single Phase Solid State Relays

HIGHLIGHTS

INPUT: DC CONTROL (TTL or CMOS

COMPATIBLE)

OUTPUT: BACK-TO-BACK SCR

(NO or NC CONFIGURATION)

OPTO ISOLATION 2500 VAC (4000 V optional)

ZERO VOLTAGE TURN-ON or RANDOM TURN-ON

SAFETY COVER (optional)

REVERSE VOLTAGE PROTECTION FOR DC/AC

RELAYS

BUILT IN SNUBBER

CHASSIS MOUNTABLE

LED INDICATOR SHOWING RELAY ‘ON’ STATUS

Weight = 106 g

Series: 1 SJ/K

10 – 40 A

(J: Zero voltage turn-on; K: Random turn-on)

ELECTRICAL SPECIFICATIONS

Parameter

Symbol

PSB 1 SJDA

481000

Type

PSB 1 SJDA

481600

PSB 1 SJDA

482500

PSB 1 SJDA

484000

Unit

DC CONTROL

Control voltage range

Control current range

Pick-up voltage

Drop-out voltage

Input resistance

OUTPUT

Mains control voltage

Repetitive peak off state voltage

RMS on-state current

Zero turn-on voltage

On-state voltage drop

Off-state leakage current @ rated voltage

Peak one cycle surge current (non-rep)

Holding current

Critical rate of rise of off-state voltage

Thermal resistance (junction to case)

Frequency range

Operating temperature

Turn-on time

Turn-off time

Fusing current

4-32

8-30

4-0

1-0

4-32

8-30

4-0

1-0

4-32

8-30

4-0

1-0

4-32

8-30

4-0

1-0

Vdc

Current regulator

RMS

DRM

TSM

dv/dt

thjc

T-on

T-off

50-480

800

1.6

100

200

2.0

47-63

-30 to +80

50-480

800

1.6

160

200

1.6

47-63

-30 to +80

128

50-480

800

1.6

500

120

200

1.0

47-63

-30 to +80

1250

50-480

800

1.6

500

250

200

0.85

47-63

-30 to +80

1250

Vac

Vpk

Vac

V/Ps

K/W

°C

released, E 197669

POWERSEM reserves the right to change limits, test conditions and dimensions -

info@POWERSEM.net

- www.POWERSEM.net
