BU7231G: DescriptionCOMPARATOR, 11000 uV OFFSET-MAX, PDSO5; CategoryAnalog mixed-signal IC Amplifier circuit; File Size516KB，19 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric View All

BU7231G Overview

COMPARATOR, 11000 uV OFFSET-MAX, PDSO5

BU7231G Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Parts packaging code	SSOP
package instruction	LSSOP,
Contacts	5
Reach Compliance Code	compli
ECCN code	EAR99
Amplifier type	COMPARATOR
Maximum input offset voltage	11000 µV
JESD-30 code	R-PDSO-G5
JESD-609 code	e2
length	2.9 mm
Nominal Negative Supply Voltage (Vsup)
Number of functions	1
Number of terminals	5
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	LSSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	1.25 mm
Supply voltage upper limit	7 V
Nominal supply voltage (Vsup)	3 V
surface mount	YES
Temperature level	INDUSTRIAL
Terminal surface	Tin/Copper (Sn/Cu)
Terminal form	GULL WING
Terminal pitch	0.95 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	1.65 mm

Preview

Download Datasheet

View All

ROHM’s Selection Operational Amplifier/Comparator Series

Comparators:

Low Voltage CMOS

BU7251G,BU7251SG,BU7231G,BU7231SG,

BU7252F/FVM,BU7252S F/FVM,BU7232F/FVM,BU7232S F/FVM

No.09049EAT06

●Description

CMOS comparator BU7251/BU7231family and BU7252/BU7232 family are input full swing and push pull output comparator.

These ICs integrate one op-amp or two independent op-amps and phase compensation capacitor on a single chip.

The features of these ICs are low operating supplyVoltage that is +1.8V to +5.5V(single supply) and low supply current,

extremely low input bias current.

High speed

Single

Dual

BU7251 G

(BU7251SG:105

℃)

BU7252 F/FVM

(BU7252S F/FVM:105

℃)

Low power

Single

Dual

BU7231 G

(BU7231SG:105

℃)

BU7232 F/FVM

(BU7232S F/FVM:105

℃)

●Features

1) Low operating supply voltage (+1.8[V]½+5.5[V])

2) +1.8 [V]½+5.5[V](single supply)

±0.9[V]½±2.75[V](split supply)

3) Input and Output full swing

4) Push-pull output type

5) High speed operation

(BU7251 family, BU7252 family)

6) Low supply current

(BU7231 family, BU7232 family)

7) Internal ESD protection

Human body model (HBM) ±4000[V](Typ.)

8) Wide temperature range

-40[℃]½+85[℃]

(BU7251G,BU7252 family, BU7231G, BU7232 family)

-40[℃]½+105[℃]

(BU7251SG,BU7252S family, BU7231SG,BU7232S family)

●

Pin Assignments

IN-

VSS

IN+

－

VDD

OUT1

IN1-

IN1+

- +

+ -

CH2

CH1

VDD

OUT2

IN2-

IN2+

＋

OUT

VSS

SSOP5

BU7251G

BU7251SG

BU7231G

BU7231SG

SOP8

BU7252F

BU7252SF

BU7232F

BU7232SF

MSOP8

BU7252FVM

BU7252SFVM

BU7232FVM

BU7232SFVM

www.rohm.com

1/18

2009.05 - Rev.A
