SMD Wire-wound Chip Inductors
ctparts.com
CT1206CSF Series
From 3.3 nH to 1200 nH
Part
Number
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CT1206CSF-3N3_
G = ±2%, J = ±5%, K = ±10%, M = ±20%
* = J, K or M only
Inductance
(nH)
3.3
6.8
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
L Test
Freq.
(MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
50
50
50
50
50
50
50
35
35
35
35
Q
Fact.
Min.
30
30
40
40
40
50
50
50
55
55
55
55
55
55
55
60
60
60
60
55
45
45
45
45
45
45
45
45
Q Test
Freq.
(MHz)
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
150
150
150
150
150
150
150
150
SRF
Min.
(MHz)
6000
5500
4000
3200
3200
2800
2200
1800
1800
1800
1500
1450
1200
1200
1100
1100
950
900
760
730
650
600
550
470
450
420
400
380
DCR
Max.
Ω
(Ω)
0.05
0.07
0.08
0.08
0.10
0.10
0.10
0.11
0.11
0.12
0.13
0.14
0.26
0.21
0.26
0.26
0.31
0.43
0.50
0.56
0.62
0.75
1.30
1.34
1.58
1.82
2.80
3.20
Rated
DC
(mA)
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
900
900
850
800
750
700
670
630
590
530
490
460
430
400
320
300
CT1206CSF-3N3_*
CT1206CSF-6N8_*
CT1206CSF-010_*
CT1206CSF-012_*
CT1206CSF-015_*
CT1206CSF-018_*
CT1206CSF-022_*
CT1206CSF-027_*
CT1206CSF-033_*
CT1206CSF-039_*
CT1206CSF-047_*
CT1206CSF-056_
CT1206CSF-068_
CT1206CSF-082_
CT1206CSF-R10_
CT1206CSF-R12_
CT1206CSF-R15_
CT1206CSF-R18_
CT1206CSF-R22_
CT1206CSF-R27_
CT1206CSF-R33_
CT1206CSF-R39_
CT1206CSF-R47_
CT1206CSF-R56_
CT1206CSF-R68_
CT1206CSF-R82_
CT1206CSF-1R0_
CT1206CSF-1R2_
Compliant
RoHS
CHARACTERISTICS
Description:
SMD ceramic core wire-wound chip inductor
Applications:
Telecommunication equipment, mobile phones,
small size pagers, computers, printers and relevant equipment.
Also, audio & video applications and the automotive electronics
industry. High frequency applications
Operating Temperature:
-40°C to +125°C
Inductance Tolerance:
±2%, ±5%, ±10%, ±20%
Testing:
Inductance and Q are tested on an HP4287A at
specified frequency
Packaging:
Tape & Reel
Marking:
Reels are marked with inductance code & tolerance
code
Miscellaneous:
RoHS Compliant.
Additional values available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
3.56
0.140
B
2.16
0.085
C
1.52
0.060
D
0.51
0.020
E
1.6
0.063
F
0.51
0.020
G
3.20
0.126
C
B
overall
F
A
G
F
PAD LAYOUT
mm
(inch)
1.95
(0.077)
1.0
(0.039)
1.8
(0.071)
1.0
(0.039)
D
E
terminal
12.08.05
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2005 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
