IHB
www.vishay.com
Vishay Dale
Filter Inductors, High Current, Radial Leaded
FEATURES
• Printed circuit mounting
• Wide range of inductance and current ratings
• Pre-tinned leads
• Optional polyolefin tubing and printing available
at additional cost
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
ELECTRICAL SPECIFICATIONS
Inductance:
Measured at 1.0 V with zero DC current
Dielectric:
2500 V
RMS
between winding and 0.250"
[6.35 mm] of insulating covering edge (with optional
insulating covering)
Current Rating:
Maximum continuous operating current
based on a + 50 °C temperature rise
Operating Temperature:
- 55 °C to + 130 °C (no load),
- 55 °C to + 80 °C (at full rated current)
MECHANICAL SPECIFICATIONS
Terminals:
Extensions of the winding wire, solder coated to
within 0.063" [1.60 mm] of body
Mounting:
Center hole for mechanical mounting, insulated
bushings recommended for center hole mounting
DIMENSIONS
in inches [millimeters]
F
(2)
B
D Dia.
0.500 ± 0.062
[12.70 ± 1.57]
E
(1)
A Dia.
MODEL
IHB-1
IHB-2
IHB-3
IHB-4
IHB-5
IHB-6
A (MAX.)
0.660 [16.76]
0.825 [20.96]
1.100 [27.94]
1.600 [40.64]
1.600 [40.64]
2.000 [50.80]
B (MAX.)
0.840 [21.34]
0.840 [21.34]
0.840 [21.34]
1.030 [26.16]
1.450 [36.83]
1.500 [38.10]
D (MIN.)
0.115 [2.92]
0.115 [2.92]
0.115 [2.92]
0.175 [4.45]
0.175 [4.45]
0.240 [6.10]
Notes
(1)
E varies between components, see individual model specifications for details, tolerance of ± 0.035
(2)
F varies between components, see individual model specifications for details
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IND. AT 1 kHz
(μH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
TOL.
(%)
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
DCR MAX.
()
0.003
0.003
0.004
0.004
0.005
0.005
0.005
0.006
0.007
0.007
0.008
0.009
0.010
0.011
0.015
0.016
0.020
0.030
0.040
0.046
RATED DC CURRENT
(A)
14.9
14.9
12.9
12.9
11.6
11.6
11.6
10.6
9.8
9.8
9.2
8.6
8.2
7.8
6.7
6.5
5.8
4.7
4.1
3.8
APPROX. LEAD “E”
SPACING
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.450 [11.43]
0.475 [12.07]
0.475 [12.07]
MAXIMUM LEAD “F”
DIAMETER
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.040 [1.02]
0.040 [1.02]
0.040 [1.02]
0.032 [0.812]
0.028 [0.723]
0.028 [0.723]
Revision: 19-Nov-13
Document Number: 34015
1
For technical questions, contact:
magnetics@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
IHB
www.vishay.com
Vishay Dale
TOL.
(%)
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 10
± 10
± 10
DCR MAX.
()
0.062
0.069
0.077
0.083
0.095
0.127
0.181
0.217
0.240
0.300
0.336
0.460
0.636
0.696
0.003
0.003
0.003
0.003
0.004
0.005
0.005
0.005
0.005
0.006
0.007
0.007
0.009
0.009
0.013
0.018
0.019
0.026
0.029
0.030
0.035
0.039
0.053
0.060
0.080
0.090
0.098
0.110
0.150
0.213
0.305
0.320
0.355
0.388
0.430
0.590
0.818
1.140
1.260
1.390
1.540
0.003
0.003
0.003
0.003
0.003
0.003
0.003
0.003
0.003
0.003
0.004
0.004
0.006
0.008
0.009
RATED DC CURRENT
(A)
3.3
3.1
2.9
2.8
2.7
2.3
1.9
1.8
1.7
1.5
1.4
1.2
1.0
1.0
17.4
17.4
17.4
17.4
15.1
13.5
13.5
13.5
13.5
12.3
11.4
11.4
10.0
10.0
8.4
7.1
6.9
5.9
5.6
5.5
5.1
4.8
4.1
3.9
3.4
3.2
3.0
2.9
2.5
2.1
1.7
1.7
1.6
1.5
1.5
1.2
1.1
0.9
0.8
0.8
0.8
20.3
20.3
20.3
20.3
20.3
20.3
20.3
20.3
20.3
20.3
17.6
17.6
14.4
12.4
11.7
APPROX. LEAD “E”
SPACING
0.470 [11.94]
0.470 [11.94]
0.500 [12.70]
0.500 [12.70]
0.500 [12.70]
0.500 [12.70]
0.500 [12.70]
0.500 [12.70]
0.500 [12.70]
0.480 [12.19]
0.480 [12.19]
0.480 [12.19]
0.475 [12.07]
0.475 [12.07]
0.620 [15.75]
0.620 [15.75]
0.620 [15.75]
0.620 [15.75]
0.620 [15.75]
0.620 [15.75]
0.620 [15.75]
0.620 [15.75]
0.620 [15.75]
0.620 [15.75]
0.620 [15.75]
0.620 [15.75]
0.620 [15.75]
0.620 [15.75]
0.620 [15.75]
0.615 [15.62]
0.615 [15.62]
0.575 [14.61]
0.575 [14.61]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.600 [15.24]
0.590 [14.99]
0.590 [14.99]
0.590 [14.99]
0.590 [14.99]
0.590 [14.99]
0.590 [14.99]
0.590 [14.99]
0.590 [14.99]
0.590 [14.99]
0.790 [20.07]
0.790 [20.07]
0.790 [20.07]
0.790 [20.07]
0.790 [20.07]
0.790 [20.07]
0.790 [20.07]
0.790 [20.07]
0.790 [20.07]
0.790 [20.07]
0.790 [20.07]
0.790 [20.07]
0.770 [19.56]
0.750 [19.05]
0.750 [19.05]
MAXIMUM LEAD “F”
DIAMETER
0.025 [0.644]
0.025 [0.644]
0.025 [0.644]
0.025 [0.644]
0.025 [0.644]
0.023 [0.573]
0.020 [0.510]
0.020 [0.510]
0.020 [0.510]
0.018 [0.455]
0.018 [0.455]
0.016 [0.405]
0.014 [0.361]
0.014 [0.361]
0.051 [1.29]
0.051 [1.29]
0.051 [1.29]
0.051 [1.29]
0.051 [1.29]
0.051 [1.29]
0.051 [1.29]
0.051 [1.29]
0.051[1.29]
0.051 [1.29]
0.051 [1.29]
0.051 [1.29]
0.051 [1.29]
0.051 [1.29]
0.045 [1.15]
0.040 [1.02]
0.040 [1.02]
0.036 [0.912]
0.036 [0.912]
0.036 [0.912]
0.036 [0.912]
0.036 [0.912]
0.032 [0.812]
0.032 [0.812]
0.028 [0.723]
0.028 [0.723]
0.028 [0.723]
0.028 [0.723]
0.025 [0.644]
0.023 [0.573]
0.020 [0.510]
0.020 [0.510]
0.020 [0.510]
0.020 [0.510]
0.020 [0.510]
0.018 [0.455]
0.016 [0.405]
0.014 [0.361]
0.014 [0.361]
0.014 [0.361]
0.014 [0.361]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.064 [1.63]
0.057 [1.45]
0.057 [1.45]
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-1
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-2
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IND. AT 1 kHz
(μH)
47
56
68
82
100
120
150
180
220
270
330
390
470
560
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
Revision: 19-Nov-13
Document Number: 34015
2
For technical questions, contact:
magnetics@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
IHB
www.vishay.com
Vishay Dale
TOL.
(%)
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
DCR MAX.
()
0.010
0.011
0.012
0.017
0.022
0.024
0.026
0.029
0.032
0.034
0.046
0.064
0.072
0.080
0.110
0.122
0.169
0.187
0.205
0.256
0.288
0.426
0.462
0.518
0.705
1.020
1.140
1.270
1.670
1.860
0.002
0.002
0.003
0.003
0.003
0.003
0.004
0.004
0.004
0.005
0.005
0.006
0.008
0.009
0.010
0.011
0.012
0.018
0.019
0.021
0.023
0.025
0.028
0.040
0.045
0.050
0.056
0.074
0.082
0.114
0.125
0.139
0.154
0.216
0.232
0.324
0.360
0.494
0.555
0.773
RATED DC CURRENT
(A)
11.1
10.6
10.2
8.5
7.5
7.2
6.9
6.5
6.2
6.0
5.2
4.4
4.1
3.9
3.4
3.2
2.7
2.6
2.5
2.2
2.1
1.7
1.6
1.5
1.3
1.1
1.0
1.0
0.9
0.8
33.8
33.8
27.6
27.6
27.6
27.6
23.9
23.9
23.9
21.4
21.4
19.5
16.9
15.9
15.1
14.4
13.8
11.3
11.0
10.4
10.0
9.6
9.0
7.6
7.1
6.8
6.4
5.6
5.3
4.5
4.3
4.1
3.9
3.3
3.1
2.7
2.5
2.2
2.0
1.7
APPROX. LEAD “E”
SPACING
0.750 [19.05]
0.750 [19.05]
0.800 [20.32]
0.780 [19.81]
0.780 [19.81]
0.760 [19.30]
0.760 [19.30]
0.760 [19.30]
0.760 [19.30]
0.760 [19.30]
0.740 [18.80]
0.720 [18.29]
0.720 [18.29]
0.790 [20.07]
0.770 [19.56]
0.770 [19.56]
0.740 [18.80]
0.740 [18.80]
0.740 [18.80]
0.725 [18.42]
0.725 [18.42]
0.715 [18.16]
0.760 [19.30]
0.760 [19.30]
0.740 [18.80]
0.720 [18.29]
0.720 [18.29]
0.720 [18.29]
0.700 [17.78]
0.730 [18.54]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.11 [28.19]
1.11 [28.19]
1.11 [28.19]
1.11 [28.19]
1.11 [28.19]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.16 [29.46]
1.13 [28.70]
1.13 [28.70]
1.13 [28.70]
1.13 [28.70]
1.13 [28.70]
1.10 [27.94]
1.10 [27.94]
1.14 [28.96]
1.14 [28.96]
1.11 [28.19]
1.11 [28.19]
1.09 [27.69]
MAXIMUM LEAD “F”
DIAMETER
0.057 [1.45]
0.057 [1.45]
0.057 [1.45]
0.051 [1.29]
0.051 [1.29]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.045 [1.150]
0.045 [1.150]
0.040 [1.020]
0.036 [0.912]
0.036 [0.912]
0.036 [0.912]
0.032 [0.812]
0.032 [0.812]
0.028 [0.723]
0.028 [0.723]
0.028 [0.723]
0.025 [0.644]
0.025 [0.644]
0.023 [0.573]
0.023 [0.573]
0.023 [0.573]
0.020 [0.510]
0.018 [0.455]
0.018 [0.455]
0.018 [0.455]
0.016 [0.405]
0.016 [0.405]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.064 [1.63]
0.064 [1.63]
0.064 [1.63]
0.064 [1.63]
0.064 [1.63]
0.057 [1.45]
0.057 [1.45]
0.057 [1.45]
0.057 [1.45]
0.057 [1.45]
0.057 [1.45]
0.051 [1.29]
0.051 [1.29]
0.051 [1.29]
0.051 [1.29]
0.045 [1.15]
0.045 [1.15]
0.040 [1.02]
0.040 [1.02]
0.040 [1.02]
0.040 [1.02]
0.036 [0.912]
0.036 [0.912]
0.032 [0.812]
0.032 [0.812]
0.028 [0.723]
0.028 [0.723]
0.025 [0.644]
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-3
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IND. AT 1 kHz
(μH)
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
Revision: 19-Nov-13
Document Number: 34015
3
For technical questions, contact:
magnetics@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
IHB
www.vishay.com
Vishay Dale
TOL.
(%)
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 20
± 20
± 20
± 20
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
DCR MAX.
()
0.845
1.140
1.600
1.760
1.950
2.760
3.040
3.390
0.002
0.002
0.002
0.002
0.003
0.003
0.003
0.003
0.003
0.004
0.004
0.005
0.007
0.007
0.008
0.009
0.010
0.011
0.013
0.015
0.017
0.018
0.022
0.025
0.035
0.040
0.044
0.049
0.070
0.078
0.105
0.115
0.127
0.176
0.195
0.274
0.302
0.338
0.459
0.642
0.699
0.775
0.843
1.150
1.260
1.740
1.920
2.170
0.002
0.002
0.003
0.003
0.003
0.004
0.004
0.005
0.005
0.006
0.006
0.006
0.008
0.009
RATED DC CURRENT
(A)
1.6
1.4
1.2
1.1
1.1
0.9
0.9
0.8
36.2
36.2
36.2
36.2
29.5
29.5
29.5
29.5
29.5
25.6
25.6
22.9
19.3
19.3
18.1
17.0
16.2
15.4
14.2
13.2
12.4
12.1
10.9
10.2
8.6
8.1
7.7
7.3
6.1
5.8
5.0
4.8
4.5
3.9
3.7
3.1
2.9
2.8
2.4
2.0
1.9
1.8
1.8
1.5
1.4
1.2
1.2
1.1
43.5
43.5
35.5
35.5
35.5
30.7
30.7
27.5
27.5
25.1
25.1
25.1
21.7
20.5
APPROX. LEAD “E”
SPACING
1.09 [27.69]
1.07 [27.18]
1.05 [26.67]
1.05 [26.67]
1.09 [27.69]
1.07 [27.18]
1.07 [27.18]
1.07 [27.18]
1.13 [28.70]
1.13 [28.70]
1.13 [28.70]
1.13 [28.70]
1.13 [28.70]
1.13 [28.70]
1.13 [28.70]
1.13 [28.70]
1.13 [28.70]
1.13 [28.70]
1.13 [28.70]
1.13 [28.70]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.10 [27.94]
1.08 [27.43]
1.08 [27.43]
1.12 [28.45]
1.12 [28.45]
1.12 [28.45]
1.12 [28.45]
1.09 [27.69]
1.09 [27.69]
1.07 [27.18]
1.07 [27.18]
1.07 [27.18]
1.05 [26.67]
1.05 [26.67]
1.03 [26.16]
1.10 [27.94]
1.10 [27.94]
1.08 [27.43]
1.06 [26.92]
1.06 [26.92]
1.06 [26.92]
1.06 [26.92]
1.04 [26.42]
1.09 [27.69]
1.07 [27.18]
1.07 [27.18]
1.07 [27.18]
1.43 [36.32]
1.43 [36.32]
1.43 [36.32]
1.43 [36.32]
1.43 [36.32]
1.43 [36.32]
1.43 [36.32]
1.43 [36.32]
1.43 [36.32]
1.43 [36.32]
1.43 [36.32]
1.43 [36.32]
1.53 [38.86]
1.53 [38.86]
MAXIMUM LEAD “F”
DIAMETER
0.025 [0.644]
0.023 [0.573]
0.020 [0.510]
0.020 [0.510]
0.020 [0.510]
0.018 [0.455]
0.018 [0.455]
0.018 [0.455]
0.081 [2.05]
0.081 [2.05]
0.081 [2.05]
0.081 [2.05]
0.081 [2.05]
0.081 [2.05]
0.081 [2.05]
0.081 [2.05]
0.081 [2.05]
0.081 [2.05]
0.081 [2.05]
0.081 [2.05]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.064 [1.63]
0.064 [1.63]
0.057 [1.45]
0.057 [1.45]
0.057 [1.45]
0.057 [1.45]
0.051 [1.29]
0.051 [1.29]
0.045 [1.15]
0.045 [1.15]
0.045 [1.15]
0.040 [1.02]
0.040 [1.02]
0.036 [0.912]
0.036 [0.912]
0.036 [0.912]
0.032 [0.812]
0.028 [0.723]
0.028 [0.723]
0.028 [0.723]
0.028 [0.723]
0.025 [0.644]
0.025 [0.644]
0.023 [0.573]
0.023 [0.573]
0.023 [0.573]
0.102 [2.59]
0.102 [2.59]
0.102 [2.59]
0.102 [2.59]
0.102 [2.59]
0.102 [2.59]
0.102 [2.59]
0.102 [2.59]
0.102 [2.59]
0.102 [2.59]
0.102 [2.59]
0.102 [2.59]
0.102 [2.59]
0.102 [2.59]
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-4
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-5
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IND. AT 1 kHz
(μH)
3900
4700
5600
6800
8200
10 000
12 000
15 000
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10 000
12 000
15 000
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
Revision: 19-Nov-13
Document Number: 34015
4
For technical questions, contact:
magnetics@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
IHB
www.vishay.com
Vishay Dale
TOL.
(%)
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
DCR MAX.
()
0.009
0.010
0.014
0.015
0.023
0.025
0.028
0.030
0.040
0.055
0.061
0.068
0.094
0.104
0.143
0.156
0.219
0.241
0.270
0.364
0.498
0.548
0.608
0.671
0.750
1.030
1.160
1.540
1.750
1.940
2.740
3.710
4.160
5.550
6.190
RATED DC CURRENT
(A)
20.5
19.4
16.4
15.9
12.8
12.3
11.6
11.2
9.7
8.3
7.9
7.5
6.3
6.0
5.1
4.9
4.2
4.0
3.7
3.2
2.8
2.6
2.5
2.4
2.2
1.9
1.8
1.6
1.5
1.4
1.2
1.0
1.0
0.8
0.8
APPROX. LEAD “E”
SPACING
1.53 [38.86]
1.53 [38.86]
1.45 [36.83]
1.45 [36.83]
1.41 [35.81]
1.41 [35.81]
1.41 [35.81]
1.41 [35.81]
1.38 [35.05]
1.35 [34.29]
1.35 [34.29]
1.35 [34.29]
1.33 [33.78]
1.33 [33.78]
1.31 [33.27]
1.40 [35.56]
1.37 [34.80]
1.37 [34.80]
1.37 [34.80]
1.34 [34.04]
1.32 [33.53]
1.32 [33.53]
1.32 [33.53]
1.38 [35.05]
1.38 [35.05]
1.35 [34.29]
1.35 [34.29]
1.33 [33.78]
1.33 [33.78]
1.38 [35.05]
1.36 [34.54]
1.33 [33.78]
1.33 [33.78]
1.31 [33.27]
1.34 [34.04]
MAXIMUM LEAD “F”
DIAMETER
0.102 [2.59]
0.102 [2.59]
0.081 [2.05]
0.081 [2.05]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.072 [1.83]
0.064 [1.63]
0.057 [1.45]
0.057 [1.45]
0.057 [1.45]
0.051 [1.29]
0.051 [1.29]
0.045 [1.15]
0.045 [1.15]
0.040 [1.02]
0.040 [1.02]
0.040 [1.02]
0.036 [0.912]
0.032 [0.812]
0.032 [0.812]
0.032 [0.812]
0.032 [0.812]
0.032 [0.812]
0.028 [0.723]
0.028 [0.723]
0.025 [0.644]
0.025 [0.644]
0.025 [0.644]
0.023 [0.573]
0.020 [0.510]
0.020 [0.510]
0.018 [0.455]
0.018 [0.455]
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IHB-6
IND. AT 1 kHz
(μH)
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10 000
12 000
15 000
18 000
22 000
27 000
33 000
39 000
47 000
MARKING
- Model
- Value
- Date code
ORDERING INFORMATION
IHB-1
MODEL
10 μH
INDUCTANCE VALUE
± 10 %
INDUCTANCE TOLERANCE
EB
PACKAGE CODE
e2
JEDEC LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER
I
H
B
1
E
B
1
0
INDUCTANCE
VALUE
0
K
INDUCTANCE
TOLERANCE
MODEL
PACKAGE
CODE
Revision: 19-Nov-13
Document Number: 34015
5
For technical questions, contact:
magnetics@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Analog electronics
京公网安备 11010802033920号
EEWORLD
