Non-RoHS
Discontinued - Not recommended for new designs
AM1D Series
•
INPUT/OUTPUT ISOLATION: 1000, 3000, 4000 & 5200VDC
•
OPERATING TEMPERATURE: -40°C ... +85°C
•
PIN-COMPATIBLE WITH MULTIPLE MANUFACTURERS
1 watt dc-dc converters
•
7PIN SIP PACKAGE
•
LOW RIPPLE & NOISE
•
HIGH EFFICIENCY UP TO 80%
DC-DC CONVERTERS
GENERAL DESCRIPTION
Our AM1D series is a family of cost effective 1W single,
dual, dual separate output isolated DC-DC converters.
These converters achieve low cost and ultra-miniature
SIP7 pin size without compromising performance and
reliability.
Two hundred sixteen models operates from input voltages
of 5, 12 & 24VDC; producing output voltage levels of 3.3,
5, 7.2, 9, 12, 15, 18, 24, ±3.3, ±5, ±7.2, ±9, ±12, ±15, ±18
& ±24VDC. Full SMD-design and a 100% production test
of parameters ensures a high reliability in this product.
ELECTRICAL SPECIFICATIONS
Specifications typical at +25°C, nominal input voltage, rated output current unless otherwise specified
Input Specifications:
Voltage
Filter
Isolation Specifications:
Rated voltage (60 sec)
±10%
Capacitor
General Specifications:
Efficiency
Switching frequency
65% to 80%
125KHz, typ. 100% load
Resistance
Capacitance
Output Specifications:
Voltage balance (dual output)
Voltage accuracy
Ripple & noise (at 20MHz BW)
Short circuit protection
Line voltage regulation
Load voltage regulation
Temperature coefficient
1000VDC (all models)
3000, 4000 & 5200VDC
(single/dual output)
> 1000MOhm
60pF, typ.
Environmental Specifications:
Operating temperature (ambient) -40°C ... +85°C
Storage temperature
-55°C ... +125°C
Case Temperature
+95°C, max.
Derating
None required
Humidity (non-condensing)
Up to 90%
Cooling
Free-air Convection
Physical Specifications:
Dimensions
Weight
Case material
±1%
±5%, max
75mVp-p, max.
Momentary
±1.2% / 1.0% of Vin
±8%, load=20~100%
±0.02%/°C, typ.
19.50x6.00x10.00mm
0.76x0.24x0.39inches
2g
Non-conductive black
plastic
MTBF: > 1,191,000 hrs (MIL-HDBK-217F, Ground Benign, t=+25°C)
Specifications are subject to change without notification
OUTLINE DIMENSIONS & PIN CONNECTIONS
Pin
Single
1000VDC
Dual
Dual Separate
3000, 4000 & 5200VDC
Single
Dual
14
1
2
4
5
6
7
+V Input
-V Input
-V Output
Omitted
+V Output
Omitted
+V Input
-V Input
-V Output
Common
+V Output
Omitted
+V Input
+V Input
+V Input
-V Input
-V Input
-V Input
+V1 Output Omitted
Omitted
-V1 Output -V Output -V Output
+V2 Output Omitted
Common
-V2 Output +V Output +V Output
TO ORDER CALL 1-888-9-AIMTEC
