Transys
Electronics
L I M I T E D
SOT-89 Plastic-Encapsulated Transistors
2SA1664
FEATURES
Power dissipation
P
CM
: 0.5
W (Tamb=25℃)
3.
EMITTER
TRANSISTOR (PNP)
SOT-89
1.
BASE
2.
COLLECTOR
1
2
3
Collector current
: -0.8
A
I
CM
Collector-base voltage
V
V
(BR)CBO
: -35
Operating and storage junction temperature range
T
J
, T
stg
: -55℃ to +150℃
ELECTRICAL CHARACTERISTICS (Tamb=25℃
Parameter
Collector-base breakdown voltage
Collector-emitter breakdown voltage
Emitter-base breakdown voltage
Collector cut-off current
Emitter cut-off current
Symbol
V
(BR)CBO
V
(BR)CEO
V
(BR)EBO
I
CBO
I
EBO
h
FE(1)
DC current gain
h
FE(2)
Collector-emitter saturation voltage
Base-emitter voltage
Transition frequency
Collector output capacitance
V
CE(sat)
V
BE
unless otherwise specified)
Test
conditions
MIN
TYP
MAX
UNIT
V
V
V
Ic=
-1
mA, I
E
=0
Ic=-10mA, I
B
=0
I
E
=
-1m
A, I
C
=0
V
CB
=
-35
V, I
E
=0
V
EB
=
-5
V, I
C
=0
V
CE
=-1V, I
C
=
-100
mA
V
CE
=
-1
V, I
C
=
-700
mA
I
C
=
-500
mA, I
B
=
-20
mA
V
CE
=
-1
V, I
C
=
-10
mA
V
CE
=
-5
V, I
C
=
-10
mA
V
CB
=
-10
V, I
E
=0, f=
1
MHz
-35
-30
-5
-0.1
-0.1
100
35
-0.7
-0.5
µA
µA
320
V
V
MHz
pF
-0.8
120
19
f
T
C
ob
CLASSIFICATION OF h
FE(1)
Rank
Range
Marking
O
100-200
RO
Y
160-320
RY
