Multi-layer Chip Inductors - Ferrite
ctparts.com
CTML0805 Series
From .047 µH to 33 µH
Part
Number
SPECIFICATIONS
Please specify tolerance code when ordering.
CTML0805-R10_
J = ±5%, K = ±10%, M = ±20%
* K or M only
CTML0805F
Please specify “F” for RoHS Compliant
Inductance
(µH)
.047
.068
.082
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
L Test
Freq.
(MHz)
50
50
50
25
25
25
25
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
4.0
4.0
4.0
2.0
2.0
1.0
1.0
1.0
1.0
.40
Q
Factor
Min.
15
15
15
20
20
20
20
20
20
25
25
25
25
25
25
45
45
45
45
45
45
45
45
45
50
50
50
45
50
30
30
30
30
30
Q Test
Freq.
(MHz)
50
50
50
25
25
25
25
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
4.0
4.0
4.0
2.0
2.0
1.0
1.0
1.0
1.0
.40
SRF
Min.
(MHz)
320
280
255
235
220
200
185
170
150
145
135
125
115
105
100
75
65
60
55
50
45
41
38
35
32
29
26
24
22
19
18
16
14
13
DCR
Max.
Ω
(Ω)
.20
.20
.20
.30
.30
.40
.40
.50
.50
.55
.65
.65
.75
.80
1.0
.40
.50
.50
.60
.65
.75
.80
.90
1.0
.90
1.0
1.1
1.1
1.2
.80
.90
1.1
1.1
1.2
Rated
DC
(mA)
Height
C
(mm)
ENGINEERING KIT #17
Not shown at actual size.
CTML0805_-R047M
CTML0805_-R068M
CTML0805_-R082M
CTML0805_-R10_
CTML0805_-R12_
CTML0805_-R15_
CTML0805_-R18_
CTML0805_-R22_
CTML0805_-R27_
CTML0805_-R33_
CTML0805_-R39_
CTML0805_-R47_
CTML0805_-R56_
CTML0805_-R68_
CTML0805_-R82_
CTML0805_-1R0_
CTML0805_-1R2_
CTML0805_-1R5_
CTML0805_-1R8_
CTML0805_-2R2_
CTML0805_-2R7_
CTML0805_-3R3_
CTML0805_-3R9_
CTML0805_-4R7_
CTML0805_-5R6_
CTML0805_-6R8_
CTML0805_-8R2_
CTML0805_-100_*
CTML0805_-120_*
CTML0805_-150_*
CTML0805_-180_*
CTML0805_-220_*
CTML0805_-270_*
CTML0805_-330_*
300 0.90±0.2
300 0.90±0.2
300 0.90±0.2
250
250
250
250
250
250
250
200
200
150
150
150
50
50
50
50
30
30
30
30
30
15
15
15
15
15
5.0
5.0
5.0
5.0
5.0
0.90±0.2
0.90±0.2
0.90±0.2
0.90±0.2
0.90±0.2
0.90±0.2
0.90±0.2
0.90±0.2
0.90±0.2
0.90±0.2
0.90±0.2
0.90±0.2
0.90±0.2
0.90±0.2
0.90±0.2
0.90±0.2
0.90±0.2
1.25±0.2
1.25±0.2
1.25±0.2
1.25±0.2
1.25±0.2
1.25±0.2
1.25±0.2
1.25±0.2
1.25±0.2
1.25±0.2
1.25±0.2
1.25±0.2
1.25±0.2
1.25±0.2
Compliant
Available
RoHS
CHARACTERISTICS
Description:
Ferrite core, multi-layer chip inductor
Applications:
LC resonant circuits such as oscillator and signal
generators, RF filters, disk drives, audio and video equipment, TV,
radio and telecommunication equipment
Operating Temperature:
-55°C to +125°C
Inductance Tolerance:
±5%, ±10% & ±20%
Testing:
Inductance and Q are tested on an HP4285A or
HP4286A at specified frequency
Packaging:
Tape & Reel
Marking:
Reels marked with inductance code and tolerance
Miscellaneous:
RoHS Compliant available
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
2±0.2
0.08±0.008
B
1.25±0.2
0.05±0.008
C
See
Ordering Info
D
0.5±0.3
0.02±0.012
PAD LAYOUT
03.18.05
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2005 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
