CORCOM Product Guide
Three Phase External Power Line Filter for Frequency Converters
FCD Series
UL Recognized
FCD10
FCD Series
The FCD filters provide three phase filtering for frequency
inverters and variable speed motor drives. Designed for
very noisy Delta applications, they attenuate conducted
interference at low and high frequency ranges and better
protect programmable logic controllers from RF noise on
the AC power line. These filters perform best when installed
on the line side of the motor drive. The FCD filters better
prevent noise from returning to the line, enabling
equipment to meet strict European regulations on RFI.
Suited for field wiring applications, these filters are ideal for
EMC troubleshooting and field refurbishing. The FCD filters
feature side flanges for easy mounting and DIN type
terminals which eliminate live metal parts, allowing safer
and easier connection. They could also be sold as an
accessory to motor drives marketed into Europe.
Specifications
Maximum leakage current,each line-to-ground
6 Amps
16 Amps
25-50 Amps
@ 120 VAC 60 Hz:
@ 250 VAC 50 Hz:
Hipot rating (one minute):
line-to-ground
line-to-line
Operating frequency:
Rated voltage (max.):
Rated current:
06FCD
16FCD
25FCD
36FCD
50FCD
2.9 mA
4.9 mA
4.9 mA
7.7 mA
5.7 mA
9.8 mA
2250 VDC
1450 VDC
50/60 Hz
480 VAC phase-to-phase
277 VAC phase-to-neutral/ground
6A
16A
25A
36A
50A
Electrical Schematics
6 Amp
LINE
LOAD
Minimum insertion loss in dB:
Line-to-ground in 50 ohm circuit
Current
Rating
6A
16A
25A
36A
50A
.01
2
13
13
9
9
Frequency–MHz
.03 .05 .1
.5
1
5
14
30
30
26
26
23
36
36
32
32
39
45
45
40
40
56
75
75
75
75
52
75
75
75
75
48
52
52
52
52
10
45
45
45
45
45
30
33
35
35
35
35
16, 25, 36 & 50 Amps
LINE
LOAD
Line-to-line in 50 ohm circuit
Current
Rating
6A
16A
25A
36A
50A
.01
9
9
9
9
9
Frequency–MHz
.03 .05 .1
.5
1
5
8
13
13
13
13
24
24
26
26
26
40
55
55
46
46
62
75
75
75
75
57
75
75
75
75
50
75
75
75
75
10
48
65
65
65
65
30
38
60
60
60
60
Resistor location for reference only.
60
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
CORCOM Product Guide
Three Phase External Power Line Filter for Frequency Converters
(Continued)
FCD Series
RFI Power Line Filters
Case Style
Slots: .260
6.61
(4)
Case Dimensions
Part No.
6FCD10
B
C
A
(max) (max) (max)
6.00
152.4
16FCD10
7.20
182.9
4.30
109.2
5.48
139.2
6.30
160.0
6.30
160.0
6.30
160.0
2.30
58.4
2.55
64.8
2.55
64.8
2.55
64.8
2.54
64.52
D
3.74
95.0
4.92
5.71
145.0
5.71
145.0
5.71
145.0
E
(max)
5.15
128.3
5.94
8.46
8.46
8.46
F
2.756
70.0
2.756
70.0
4.528
4.528
4.528
124.97 150.9
B
D
L
I
N
E
LABEL
L
O
A
D
25FCD10
9.69
246.1
36FCD10
9.69
246.1
50FCD10
10.5
266.7
215.0 115.01
215.0 115.01
215.0 115.01
F
E
Part Numbers
06FCD10
16FCD10
25FCD10
36FCD10
50FCD10
A
C
Note: Terminals No. 8-32 (2)
Type (qty.)
Torque in. lb.
6FCD10, 16FCD10
VDFK4 (6)
5.31 min.
Phoenix contacts
Accepts 12 AWG stranded wire. Strip length 0.315
25FCD10, 36FCD10
Phoenix contacts
VDFK6 (6)
13.28 min.
Accepts 10 AWG stranded wire. Strip length 0.354
50FCD10
Phoenix contacts
HDFK10-VP (6)
13.28 min
Accepts 8 AWG stranded wire. Strip length 0.433
61
Catalog 1654001
Revised 05-07
Dimensions are in inches and
millimeters unless otherwise
specified. Values in italics
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA Cust. Svc.: 1-800-468-2023
CORCOM Prods: 1-847-680-7400
Germany:
49-89-6089-0
www.corcom.com
www.tycoelectronics.com
