Common mode
SS Coils
SS17HB Type
[RoHS Compliant]
[RoHS Compliant]
Model
SS17HB-03225
SS17HB-04125
SS17HB-05100
SS17HB-06085
SS17HB-07065
SS17HB-08050
SS17HB-10025
SS17HB-11020
SS17HB-13018
SS17HB-17008
SS17HB-R03300
SS17HB-R04170
SS17HB-R05140
SS17HB-R06120
SS17HB-R07090
SS17HB-R08070
SS17HB-R10035
SS17HB-R11025
SS17HB-R13020
SS17HB-R17010
Rated
current
AC(A)
0.3
0.4
0.5
0.6
0.7
0.8
1.0
1.1
1.3
1.7
0.3
0.4
0.5
0.6
0.7
0.8
1.0
1.1
1.3
1.7
Wire
diameter
（mm）
0.20
0.23
0.25
0.28
0.30
0.30
0.37
0.37
0.40
0.45
0.20
0.23
0.25
0.28
0.30
0.30
0.37
0.37
0.40
0.45
Inductance
(mH)
min.
22.5
12.5
10.0
8.5
6.5
5.0
2.5
2.0
1.5
0.8
30.0
17.0
14.0
12.0
9.0
7.0
3.5
2.5
2.0
1.0
DC resistance
( /line)
max.
2.60
1.40
1.10
0.84
0.70
0.45
0.38
0.24
0.18
0.12
2.60
1.40
1.10
0.84
0.70
0.45
0.38
0.24
0.18
0.12
Temperature
rise(K)
max.
48
53
55
45
50
58
50
65
55
55
48
53
55
45
50
58
50
65
55
55
Marking
03 Lot No.
04 Lot No.
05 Lot No.
06 Lot No.
07 Lot No.
08 Lot No.
10 Lot No.
11 Lot No.
13 Lot No.
17 Lot No.
R03 Lot No.
R04 Lot No.
R05 Lot No.
R06 Lot No.
R07 Lot No.
R08 Lot No.
R10 Lot No.
R11 Lot No.
R13 Lot No.
R17 Lot No.
Weight
approx.
(g)
5.9
6.5
6.4
6.0
6.0
5.9
6.3
6.3
6.2
6.1
5.9
6.5
6.4
6.0
6.0
5.9
6.3
6.3
6.2
6.1
• Rated voltage:250V AC/DC
• Thermal class:E(120℃)
• Withstanding voltage:AC 2400V for 2seconds
（between
lines）
• Operating temperature range(℃):-25 to T (T=120-temperature rise)
• Inductance measurement condition:1kHz, 1V, KC530 or equivalent
Shape and Dimensions
bSS17HB
20max.
2.5±0.5 13.8max.
Marking
17.85max.
ø0.7±0.1
16±0.5
10±0.5
16
Numbering System
SS 17HB -
03 225
Series name
Core size(H shows a horizontal type)
Core type(Nothing shows standard core type, R shows a high-μ core type)
Current rating(03 shows 0.3A)
Inductance(225 shows 22.5mH)
AC Line Filters VOL.08
●All specifications in this catalog and production status of products are subject to change without notice. Prior to the purchase, please contact NEC TOKIN for updated product data.
●Please request for a specification sheet for detailed product data prior to the purchase.
