IRF3415-002: DescriptionSmall Signal Field-Effect Transistor, 37A I(D), 150V, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-220AB; CategoryDiscrete semiconductor The transistor; File Size203KB，9 Pages; ManufacturerInternational Rectifier （ Infineon ）; Websitehttp://www.irf.com/

Download Datasheet Parametric View All

IRF3415-002 Overview

Small Signal Field-Effect Transistor, 37A I(D), 150V, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-220AB

IRF3415-002 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	International Rectifier （ Infineon ）
package instruction	FLANGE MOUNT, R-PSFM-T3
Reach Compliance Code	compliant
ECCN code	EAR99
Configuration	SINGLE
Minimum drain-source breakdown voltage	150 V
Maximum drain current (ID)	37 A
Maximum drain-source on-resistance	0.042 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR
JEDEC-95 code	TO-220AB
JESD-30 code	R-PSFM-T3
JESD-609 code	e0
Number of components	1
Number of terminals	3
Operating mode	ENHANCEMENT MODE
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	225
Polarity/channel type	N-CHANNEL
Certification status	Not Qualified
surface mount	NO
Terminal surface	TIN LEAD
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Maximum time at peak reflow temperature	30
Transistor component materials	SILICON

Preview

Download Datasheet

View All

PD - 94963

IRF3415PbF

Advanced Process Technology

Dynamic dv/dt Rating

175°C Operating Temperature

Fast Switching

Fully Avalanche Rated

Lead-Free

HEXFET

Power MOSFET

DSS

= 150V

DS(on)

= 0.042Ω

Description

Fifth Generation HEXFETs from International Rectifier

utilize advanced processing techniques to achieve

extremely low on-resistance per silicon area. This

benefit, combined with the fast switching speed and

ruggedized device design that HEXFET Power

MOSFETs are well known for, provides the designer

with an extremely efficient and reliable device for use

in a wide variety of applications.

The TO-220 package is universally preferred for all

commercial-industrial applications at power dissipation

levels to approximately 50 watts. The low thermal

resistance and low package cost of the TO-220

contribute to its wide acceptance throughout the

industry.

= 43A

TO-220AB

Absolute Maximum Ratings

Parameter

@ T

= 25°C

@ T

= 100°C

= 25°C

dv/dt

STG

Continuous Drain Current, V

@ 10V

Continuous Drain Current, V

@ 10V

Pulsed Drain Current

Power Dissipation

Linear Derating Factor

Gate-to-Source Voltage

Single Pulse Avalanche Energy

Avalanche Current

Repetitive Avalanche Energy

Peak Diode Recovery dv/dt

Operating Junction and

Storage Temperature Range

Soldering Temperature, for 10 seconds

Mounting torque, 6-32 or M3 srew

Max.

150

200

1.3

± 20

590

5.0

-55 to + 175

300 (1.6mm from case )

10 lbfin (1.1Nm)

Units

W/°C

V/ns

°C

Thermal Resistance

Parameter

θJC

θCS

θJA

Junction-to-Case

Case-to-Sink, Flat, Greased Surface

Junction-to-Ambient

Typ.

0.50

Max.

0.75

Units

°C/W

1/30/04
