Aluminum Electrolytic Capacitors/ EB(Large Can Size)
Surface Mount Type
Series:
EB
(Large Can Size)
Type:
V
■
Features
●
Endurance : 105 °C 3000 h to 5000 h
●
RoHS directive compliant
■
Specifications
Category Temp. Range
Rated W.V. Range
Nominal Cap. Range
Capacitance Tolerance
DC Leakage Current
tan
δ
Characteristics
at Low Temperature
W.V. (V)
Z(–25 °C) / Z(+20 °C)
160
2
–25 °C to +105 °C
160 V.DC to 450 V.DC
2.2 µF to 100 µF
±20 % (120 Hz/+20 °C)
I
<
0.06 CV +10 (µA) After 2 minutes
Please see the attached standard products list
200
250
350
400
450
(Impedance ratio at 120 Hz)
2
3
5
6
6
After the life test with DC rated working voltage at +105 °C±2 °C for 5000 hours, the capacitors shall meet
the limits specified below. (Size code G13 : 3000 hours, G17 : 4000 hours)
Endurance
Capacitance change ±20 % of initial measured value
tan
δ
<
200 % of initial specified value
DC leakage current
<
initial specified value
After storage for 1000 hours at +105 °C±2 °C with no voltage applied and then being stabilized at +20 °C,
capacitors shall meet the limits specified in Endurance. (With voltage treatment)
After reflow soldering and then being stabilized at +20 °C, capacitors shall meet the following limits.
Capacitance change ±10 % of initial measured value
tan
δ
<
initial specified value
DC leakage current
<
initial specified value
Shelf Life
Resistance to
Soldering Heat
■
Marking
Example : 160 V 10 µF
■
Dimensions in mm (not to scale)
( )reference size
0.3 max.
A±0.2
–
φD±0.5
Series identification
H
Negative polarity
marking (–)
2C EB
W
(I)
L±0.5
Lot number
Rated Voltage Mark
2C
2D
2E
2V
2G
2W
160 V
200 V
250 V
350 V
400 V
450 V
+
(P)
10
B±0.2
Capacitance (µF)
(I)
K
Rated Voltage Mark
(mm)
Size
code
G13
G17
H16
J16
J21
K16
K21
D
10.0
10.0
12.5
16.0
16.0
18.0
18.0
L
13.5
16.5
16.5
16.5
21.5
16.5
21.5
A,B H max.
10.3
10.3
13.5
17.0
17.0
19.0
19.0
12.0
12.0
15.0
19.0
19.0
21.0
21.0
I
3.5
3.5
4.7
5.5
5.5
6.7
6.7
W
0.9±0.2
0.9±0.2
0.9±0.2
1.2±0.3
1.2±0.3
1.2±0.3
1.2±0.3
P
4.6
4.6
4.4
6.7
6.7
6.7
6.7
K
0.70±0.20
0.70±0.20
0.70±0.30
0.70±0.30
0.70±0.30
0.70±0.30
0.70±0.30
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
01 Nov. 2008
– EE75 –
Aluminum Electrolytic Capacitors/ EB(Large Can Size)
■
Standard Products
Case size
W.V.
Cap.
(±20 %)
Size
Code
Specification
tan
δ
Endurance
Ripple
Part No.
Current
(RoHS:compliant)
(100 kHz) (120 Hz)
(+105 °C) (+20 °C)
(mA)
(hours)
EEVEB2C100Q
70
0.15
3000
470
600
750
750
1060
80
470
600
600
750
1060
88
560
560
710
990
38
50
270
350
480
670
40
50
250
410
600
29
41
49
310
560
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.20
0.20
0.20
0.20
0.20
0.20
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
5000
5000
5000
5000
5000
4000
5000
5000
5000
5000
5000
4000
5000
5000
5000
5000
3000
4000
5000
5000
5000
5000
3000
4000
5000
5000
5000
3000
4000
5000
5000
5000
EEVEB2C330SQ
EEVEB2C470SM
EEVEB2C680M
EEVEB2C680SM
EEVEB2C101M
EEVEB2D100Q
EEVEB2D220SQ
EEVEB2D330SM
EEVEB2D470SM
EEVEB2D680M
EEVEB2D101M
EEVEB2E100Q
EEVEB2E220SM
EEVEB2E330SM
EEVEB2E470M
EEVEB2E680M
EEVEB2V3R3Q
EEVEB2V4R7Q
EEVEB2V100SM
EEVEB2V220SM
EEVEB2V330M
EEVEB2V470M
EEVEB2G3R3Q
EEVEB2G4R7Q
EEVEB2G100SM
EEVEB2G220M
EEVEB2G330M
EEVEB2W2R2Q
EEVEB2W3R3Q
EEVEB2W4R7SQ
EEVEB2W100SM
EEVEB2W220M
Reflow
Endurance : 105 °C 5000 h (G13 : 3000 h, G17 : 4000 h)
Min.
Packaging Q'ty
Taping
(pcs)
250
150
125
75
125
75
200
150
125
125
75
75
200
125
125
75
75
250
200
125
125
75
75
250
200
125
75
75
250
200
150
125
75
Dia.
(mm)
10
12.5
16
16
18
18
10
12.5
16
18
16
18
10
16
18
16
18
10
10
16
18
16
18
10
10
16
16
18
10
10
12.5
18
18
Length
(mm)
13.5
16.5
16.5
21.5
16.5
21.5
16.5
16.5
16.5
16.5
21.5
21.5
16.5
16.5
16.5
21.5
21.5
13.5
16.5
16.5
16.5
21.5
21.5
13.5
16.5
16.5
21.5
21.5
13.5
16.5
16.5
16.5
21.5
(V)
(µF)
10
33
47
68
100
10
22
33
47
68
100
10
22
G13
H16
J16
J21
K16
K21
G17
H16
J16
K16
J21
K21
G17
J16
K16
J21
K21
G13
G17
J16
K16
J21
K21
G13
G17
J16
J21
K21
G13
G17
H16
K16
K21
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
160
200
250
33
47
68
3.3
4.7
10
22
33
47
3.3
4.7
350
400
10
22
33
2.2
3.3
450
4.7
10
22
The taping dimensions are explained on p.177 of our Catalog.
Please use it as a reference guide.
Reflow profile(Fig-1 to Fig-8) listed on p.175 of our Catalog.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
01 Nov. 2008
– EE76 –
