MMBZ6V8ALQ-7-F datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> MMBZ6V8ALQ-7-F

MMBZ6V8ALQ-7-F: DescriptionTrans Voltage Suppressor Diode, 24W, 4.5V V(RWM), Unidirectional, 2 Element, Silicon, GREEN, PLASTIC PACKAGE-3; CategoryDiscrete semiconductor diode; File Size194KB，6 Pages; ManufacturerDiodes; Websitehttp://www.diodes.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

MMBZ6V8ALQ-7-F Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MMBZ6V8ALQ-7-F	-	-	View	Buy Now

MMBZ6V8ALQ-7-F Overview

Trans Voltage Suppressor Diode, 24W, 4.5V V(RWM), Unidirectional, 2 Element, Silicon, GREEN, PLASTIC PACKAGE-3

MMBZ6V8ALQ-7-F Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Diodes
package instruction	R-PDSO-G3
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	30 weeks
Other features	HIGH RELIABILITY
Maximum breakdown voltage	7.14 V
Minimum breakdown voltage	6.46 V
Breakdown voltage nominal value	6.8 V
Maximum clamping voltage	9.6 V
Configuration	COMMON ANODE, 2 ELEMENTS
Diode component materials	SILICON
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
JESD-30 code	R-PDSO-G3
JESD-609 code	e3
Humidity sensitivity level	1
Maximum non-repetitive peak reverse power dissipation	24 W
Number of components	2
Number of terminals	3
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.225 W
Guideline	AEC-Q101
Maximum repetitive peak reverse voltage	4.5 V
surface mount	YES
technology	AVALANCHE
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	40

Preview

Download Datasheet

View All

MMBZ5V6AL - MMBZ33VAL

24W AND 40W PEAK POWER DUAL SURFACE MOUNT TVS

Features

•

Dual TVS in Common Anode Configuration

24W/40W Peak Power Dissipation Rating @ 1.0ms

(Unidirectional)

225mW Power Dissipation

Ideally Suited for Automated Insertion

Low Leakage

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 Standards for High Reliability

Mechanical Data

•

Case: SOT23

Case Material: Molded Plastic “Green” Molding Compound.

Flammability Classification 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminals: Solderable per MIL-STD-202, Method 208

Polarity: See Diagram

Lead Free Plating (Matte Tin Finish annealed over Alloy 42

leadframe).

ESD Rating Exceeding 16kV per the Human Body Model (Note 8)

Marking Information: See Below

Ordering Information: See Below

Weight: 0.008 grams (approximate)

Top View

Device Schematic

Ordering Information

Part Number

(Type Number)-7*-F

(Type Number)Q-7*-F

(Note 4)

Qualification

Commercial

Automotive

Case

SOT23

Packaging

3000/Tape & Reel

* Example: 5.6V type = MMBZ5V6AL-7-F.

Notes:

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. For packaging details, go to our website at http://www.diodes.com.

Marking Information

xxx = Product type marking code,

See Electrical Characteristics Table, Pages 2

YM = Date Code Marking

Y = Year (ex: A = 2013)

M = Month (ex: 9 = September)

xxx

Date Code Key

Year

Code

Month

Code

2006

Jan

2007

Feb

2008

Mar

2009

Apr

2010

May

2011

Jun

2012

Jul

2013

2014

Aug

2015

Sep

2016

Oct

2017

Nov

2018

Dec

MMBZ5V6AL - MMBZ33VAL

Document number: DS30306 Rev. 14 - 2

1 of 6

www.diodes.com

January 2013

MMBZ6V8ALQ-7-F Related Products

	MMBZ6V8ALQ-7-F	MMBZ9V1ALQ-7-F	MMBZ15VALQ-7-F	MMBZ10VALQ-7-F	MMBZ18VALQ-7-F	MMBZ20VALQ-7-F	MMBZ27VALQ-7-F	MMBZ6V2ALQ-7-F
Description	Trans Voltage Suppressor Diode, 24W, 4.5V V(RWM), Unidirectional, 2 Element, Silicon, GREEN, PLASTIC PACKAGE-3	Trans Voltage Suppressor Diode, 24W, 6V V(RWM), Unidirectional, 2 Element, Silicon, GREEN, PLASTIC PACKAGE-3	Trans Voltage Suppressor Diode, 40W, 12V V(RWM), Unidirectional, 2 Element, Silicon, GREEN, PLASTIC PACKAGE-3	Trans Voltage Suppressor Diode, 24W, 6.5V V(RWM), Unidirectional, 2 Element, Silicon, GREEN, PLASTIC PACKAGE-3	Trans Voltage Suppressor Diode, 40W, 14.5V V(RWM), Unidirectional, 2 Element, Silicon, GREEN, PLASTIC PACKAGE-3	Trans Voltage Suppressor Diode, 40W, 17V V(RWM), Unidirectional, 2 Element, Silicon, GREEN, PLASTIC PACKAGE-3	Trans Voltage Suppressor Diode, 40W, 22V V(RWM), Unidirectional, 2 Element, Silicon, GREEN, PLASTIC PACKAGE-3	Trans Voltage Suppressor Diode, 24W, 3V V(RWM), Unidirectional, 2 Element, Silicon, GREEN, PLASTIC PACKAGE-3
Is it lead-free?	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to
Maker	Diodes	Diodes	Diodes	Diodes	Diodes	Diodes	Diodes	Diodes
package instruction	R-PDSO-G3	GREEN, PLASTIC PACKAGE-3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Other features	HIGH RELIABILITY	HIGH RELIABILITY	HIGH RELIABILITY	HIGH RELIABILITY	HIGH RELIABILITY	HIGH RELIABILITY	HIGH RELIABILITY	HIGH RELIABILITY
Maximum breakdown voltage	7.14 V	9.56 V	15.75 V	10.5 V	18.9 V	21 V	28.35 V	6.51 V
Minimum breakdown voltage	6.46 V	8.65 V	14.25 V	9.5 V	17.1 V	19 V	25.65 V	5.89 V
Breakdown voltage nominal value	6.8 V	9.1 V	15 V	10 V	18 V	20 V	27 V	6.2 V
Maximum clamping voltage	9.6 V	14 V	21 V	14.2 V	25 V	28 V	40 V	8.7 V
Configuration	COMMON ANODE, 2 ELEMENTS	COMMON ANODE, 2 ELEMENTS	COMMON ANODE, 2 ELEMENTS	COMMON ANODE, 2 ELEMENTS	COMMON ANODE, 2 ELEMENTS	COMMON ANODE, 2 ELEMENTS	COMMON ANODE, 2 ELEMENTS	COMMON ANODE, 2 ELEMENTS
Diode component materials	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE	TRANS VOLTAGE SUPPRESSOR DIODE	TRANS VOLTAGE SUPPRESSOR DIODE	TRANS VOLTAGE SUPPRESSOR DIODE	TRANS VOLTAGE SUPPRESSOR DIODE	TRANS VOLTAGE SUPPRESSOR DIODE	TRANS VOLTAGE SUPPRESSOR DIODE	TRANS VOLTAGE SUPPRESSOR DIODE
JESD-30 code	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3	R-PDSO-G3
JESD-609 code	e3	e3	e3	e3	e3	e3	e3	e3
Humidity sensitivity level	1	1	1	1	1	1	1	1
Maximum non-repetitive peak reverse power dissipation	24 W	24 W	40 W	24 W	40 W	40 W	40 W	24 W
Number of components	2	2	2	2	2	2	2	2
Number of terminals	3	3	3	3	3	3	3	3
Maximum operating temperature	150 °C	150 °C	150 °C	150 °C	150 °C	150 °C	150 °C	150 °C
Minimum operating temperature	-65 °C	-65 °C	-65 °C	-65 °C	-65 °C	-65 °C	-65 °C	-65 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260	260	260	260	260	260	260	260
polarity	UNIDIRECTIONAL	UNIDIRECTIONAL	UNIDIRECTIONAL	UNIDIRECTIONAL	UNIDIRECTIONAL	UNIDIRECTIONAL	UNIDIRECTIONAL	UNIDIRECTIONAL
Maximum power dissipation	0.225 W	0.225 W	0.225 W	0.225 W	0.225 W	0.225 W	0.225 W	0.225 W
Guideline	AEC-Q101	AEC-Q101	AEC-Q101	AEC-Q101	AEC-Q101	AEC-Q101	AEC-Q101	AEC-Q101
Maximum repetitive peak reverse voltage	4.5 V	6 V	12 V	6.5 V	14.5 V	17 V	22 V	3 V
surface mount	YES	YES	YES	YES	YES	YES	YES	YES
technology	AVALANCHE	AVALANCHE	AVALANCHE	AVALANCHE	AVALANCHE	AVALANCHE	AVALANCHE	AVALANCHE
Terminal surface	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	40	40	40	40	40	40	40	40
Factory Lead Time	30 weeks	30 weeks	19 weeks	-	19 weeks	18 weeks 4 days	19 weeks	-
