70430-0221: Description12 CONTACT(S), FEMALE, FFC/FPC CONNECTOR; CategoryThe connector The connector; File Size133KB，2 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home

Download Datasheet Parametric Compare View All

70430-0221 Overview

12 CONTACT(S), FEMALE, FFC/FPC CONNECTOR

70430-0221 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknow
Connector type	FFC/FPC CONNECTOR
Contact to complete cooperation	GOLD (15) OVER NICKEL (50)
Contact completed and terminated	GOLD (15) OVER NICKEL (50)
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e4
MIL compliance	NO
Mixed contacts	NO
Installation type	CABLE
Number of rows loaded	1
Options	GENERAL PURPOSE
Total number of contacts	12
UL Flammability Code	94V-0
Base Number Matches	1
