YAGEO CORPORATION
SMD INDUCTOR / BEADS
DIP Power Inductors
PMC Series
electrical characteristics : lead free & rOhs cOmpliance
part
nO.
inductance tOlerance
at
(±%)
(µH)
test
freQuencY
(KHZ)
ser
(KhZ)
MIN.
dc
resistance
(mΩ)MAX
rated
current
(A)MIN
PMC129B-R30M-N
PMC129B-R50M-N
PMC129B-R60M-N
PMC129B-R90M-N
PMC129B-1R2M-N
PMC129B-1R5M-N
PMC129B-2R2M-N
PMC129B-3R3M-N
PMC129B-4R7M-N
PMC127B-R60M-N
PMC127B-1R0M-N
PMC127B-1R5M-N
PMC127B-2R2M-N
PMC127B-3R3M-N
Internal No.
Tolerance
Inductance
Packaging(T:tape & Reel)
Dimensions
Product Symbol
0.30
0.50
0.60
0.90
1.20
1.50
2.20
3.30
4.70
0.60
1.00
1.50
2.20
3.30
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
100
100
100
100
100
100
100
100
100
100
100
100
100
100
0.8
1.0
1.0
1.8
2.0
2.2
3.0
3.0
5.0
1.0
2.0
2.0
3.0
4.5
60
40
40
30
30
25
20
15
15
30
30
25
20
20
features
Magnetic shielded construction for high density
board assembly
High performance execllent DC current
characteristics
Large energy storage capacity
Up to 40 amps continuous
Custom designs available
prOduct identificatiOn
PMC
-
-
Note: * at 25MHZ
** at 7.9MHZ
When ordering please specify tolerance and packaging code.
Ex : PMC129- R60M- S Tolerance: M±20%, L±15%, K±10% Packaging: Clear Tape and Reel (Standard)
L Q :HP4287A
SRF :HP8753D/E4991A RDC: Digital Multimeter SC-7401
Operating Temperature °C Range -40°C to +125°C
shape and dimensiOns
PMC129
Dimensions : mm
10(MAX)
14(MAX)
laY Out
14(MAX)
PMC127
R0.8
1.6
)
IN
.8(M
ø1
11.5±0.5
8.5(MAX)
14(MAX)
14(MAX)
11.5±0.5
5.5±0.5
5.5±0.5
2.7
