F-203-1
FFMD–20–T–02.00–01–N–R
FFMD–10–S–10.00 – 01–RW
. 050"
(1,27mm)
CABLE PLUG
FFMD SERIES
Mates with:
FLE, SFMC
TYPE
STRIP
NO. PINS
PER ROW
END
OPTION
OVERALL
LENGTH
01
TRANSFER
OPTION
OTHER
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?FFMD
Insulator Material:
Black Glass Filled
Polyester
Terminal:
Phospor Bronze
Current Rating:
Testing Now!
Operating Temp Range:
-40°C to +105°C
Plating:
10µ" (0,25µm) Au over 50µ"
(1,27µm) Ni
Wire:
30 AWG
Leave blank for
–S and –D
End Options.
For –T
End Option
Specify “–N”
(Socket
has notch
polarization)
–05, –10, –13,
–17, –20, –25
(Call for other sizes)
= Assembled Length
Assembled Length
in INCHES (±1/8")
2 inches minimum
–“XX.XX”
Example: 04.00= (101,6mm) 4.00"
–S
= Single End
–D
= Double End
–T
= Transfer End
= Reverse Wiring
–RW
–R
= Reversed
FFMD
= Terminal Strip
01
3
01
02
(3,05)
.120
Blue or black wire
opposite position #1.
1
= Middle Reverse
–M
No. of Positions x
.050 (1,27) + .165 (4,19)
–D “XX”
= Daisy Chain
2"
min.
“XX”
Requires –DXX
(5,08)
.200
±
1/8"
3
= Outside Reverse
(3,07)
.121
(0,41) .016 SQ
(1,27)
.050
2
4" minimum
–O
Note:
This Series is
non-standard, non-returnable.
Requires –DXX
3
Due to technical progress, all designs, specifications and components are subject to change without notice.
