85003-9000: Description2.54mm (.100") Pitch DIN 41612 C Style Male Header, Right Angle, Through Hole; File Size68KB，3 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home

Download Datasheet View All

85003-9000 Overview

2.54mm (.100") Pitch DIN 41612 C Style Male Header, Right Angle, Through Hole

Preview

Download Datasheet

View All

This document was generated on 05/17/2010

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMA

Part Number:

Status:

Overview:

Description:

0850039000

Active

din_41612

2.54mm (.100") Pitch DIN 41612 C Style Male Header, Right Angle, Through Hole,

0.60µm (24µ") Selective Gold (Au) Plating, 96 Circuits, with Mounting Clips, No Flux

Proof, Lead free, High Temperature version

Documents:

Drawing (PDF)

RoHS Certificate of Compliance (PDF)

EU RoHS

ELV and

Complia

REACH S

Not Revie

Halogen

Status

Not Revi

Need mo

environm

Agency Certification

CSA

LR19980

E29179

Email pro

For a mu

Complian

General

Product Family

Series

Application

Comments

Component Type

Overview

Product Name

Style

Backplane Connectors

85003

Backplane

With Mounting Clips. No Flux Proof

PCB Header

din_41612

IEC 603-2/DIN 41612

Please vi

non-prod

85003S

Physical

Circuits (Loaded)

Circuits (maximum)

Circuits Detail

Color - Resin

Durability (mating cycles max)

First Mate / Last Break

Flammability

Guide to Mating Part

Keying to Mating Part

Material - Metal

Material - Plating Mating

Material - Plating Termination

Material - Resin

Number of Columns

Number of Pairs

Number of Rows

Orientation

PC Tail Length (in)

PC Tail Length (mm)

PCB Locator

PCB Retention

PCB Thickness Recommended (in)

PCB Thickness Recommended (mm)

Packaging Type

Pitch - Mating Interface (in)

Pitch - Mating Interface (mm)

Pitch - Term. Interface (in)

Pitch - Term. Interface (mm)

Plating min: Mating (µin)

Plating min: Mating (µm)

Standard Contacts at: A:a2-a31; B:b1-b32; C:c1-c32.

Last-Mate-First- Break Contacts at: D:a1,a32

Natural

400

94V-0

Yes

Brass

Gold

Tin

High Temperature Thermoplastic

Open Pin Field

Right Angle

0.118 In

3.00 mm

Yes

0.062 In

1.60 mm

Carton

0.100 In

2.54 mm

0.100 In

2.54 mm

0.60
