DR1
Power Line
Chokes
.660" max
.5"
.840" max
A
TYPICAL APPLIC
ATIONS
Filters
Power Supplies
RFI Supression
Power Amplifiers
Switching Regulators
SCR and Triac Controls
Speaker and Crossover Networks
GENERAL CHARACTERISTICS
DR1 Power Line Chokes are available in Inductancesranging
from 1 to 560 µh with Saturation Currents ranging from 2.9 to
87 amps DC. High saturation material makes these chokes
ideal for applications needing both high-current values and
small size. Supplied in bulk only.
Notes:
(1) Sa tura tion curr ent lo w er s inductance 5%.
(2) Leads ar e tinned to within 1/16 in. of body .
(3) Coils ar e f inished with UL-VW -1 ra ted sleeving.
PART
NUMBER
DR1-1R0K
DR1-1R2K
DR1-1R5K
DR1-1R8K
DR1-2R2K
DR1-2R7K
DR1-3R3K
DR1-3R9K
DR1-4R7K
DR1-5R6K
DR1-6R8K
DR1-8R2K
DR1-100K
DR1-120K
DR1-150K
DR1-180K
DR1-220K
DR1-270K
DR1-330K
DR1-390K
DR1-470K
DR1-560K
DR1-680K
DR1-820K
DR1-101K
DR1-121K
DR1-151K
DR1-181K
DR1-221K
DR1-271K
DR1-331K
DR1-391K
DR1-471K
DR1-561K
INDUCTANCE
(µH ± 10%)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100.0
120.0
150.0
180.0
220.0
270.0
330.0
390.0
470.0
560.0
DC RESISTANCE
OHMS
MAXIMUM (Ω )
.003
.003
.004
.004
.004
.005
.005
.006
.007
.007
.007
.008
.009
.010
.011
.015
.020
.030
.040
.046
.062
.069
.077
.083
.095
.127
.181
.217
.240
.300
.336
.460
.636
.696
CURRENT
SATURATING
AMPS DC (1)
87.0
68.0
56.0
56.0
47.0
47.0
40.0
36.0
32.0
29.0
26.0
24.5
21.2
19.0
17.5
16.5
15.8
14.4
13.2
11.8
11.0
10.0
8.9
8.2
7.5
5.8
5.6
5.1
4.3
4.1
3.8
3.3
3.2
2.9
WIRE
DIAMETER
0.071
0.071
0.071
0.067
0.063
0.063
0.059
0.059
0.055
0.055
0.055
0.055
0.051
0.051
0.047
0.047
0.039
0.039
0.039
0.039
0.035
0.035
0.035
0.031
0.029
0.029
0.027
0.027
0.026
0.020
0.021
0.021
0.020
0.020
DIMENSION (A)
.550
.550
.550
.550
.550
.550
.550
.550
.550
.550
.550
.550
.550
.550
.550
.550
.550
.550
.406
.469
.469
.485
.500
.500
.500
.480
.480
.480
.480
.480
.480
.480
.450
.450
