XFSMD3 SERIES INDUCTORS

Preview

Download Datasheet

View All

XFMRS

XFSMD3 SERIES INDUCTORS

TRUE SURFACE MOUNT DESIGN

ECONOMICAL, LOW COST SOLUTION TO YOUR POWER REQUIREMENTS

CUSTOM VERSIONS AVAILABLE AT NO EXTRA COST

TAPE AND REEL PACKAGING AVAILABLE

LOW LOSS MPP CORE OR POWDERED IRON VERSIONS, BOTH STANDARD

VERSATILE DUAL WINDING DESIGN, USE AS HIGH CURRENT CHOKE OR

ONE (1) TO ONE (1) TRANSFORMER

• CONSTANT INDUCTANCE UP TO 1.0 MHz

•

PARALLEL RATINGS

PART

NUMBER

6XF4709-S3

6XF6809-S3

6XF0016-S3

6XF0026-S3

6XF0056-S3

6XF0086-S3

6XF0106-S3

6XF0156-S3

6XF0206-S3

6XF0256-S3

6XF0336-S3

6XF0506-S3

6XF0686-S3

6XF1006-S3

6XF1506-S3

6XF2006-S3

6XF3006-S3

7XF4709-S3

7XF6809-S3

7XF0016-S3

7XF0026-S3

7XF0056-S3

7XF0086-S3

7XF0106-S3

7XF0156-S3

7XF0206-S3

7XF0256-S3

7XF0336-S3

7XF0506-S3

7XF0686-S3

7XF1006-S3

7XF1506-S3

7XF2006-S3

7XF3006-S3

INDUCTANCE CURRENT

µH

ADC

.42

.75

1.18

2.30

4.70

7.94

10.58

15.23

20.73

24.86

31.77

51.18

67.87

99.45

147.39

198.58

300.80

.44

.78

1.23

1.76

4.90

8.28

9.60

14.16

19.60

25.92

33.12

50.18

67.08

99.23

148.23

200.70

298.12

6.50

5.50

4.60

4.50

3.00

2.60

2.50

1.70

1.30

1.00

1.40

.92

.78

.63

.43

.39

.38

7.00

6.00

5.00

5.90

4.40

3.50

3.40

3.00

2.10

2.00

1.80

1.50

1.20

.92

.82

.64

.62

DCR

OHMS

.005

.006

.008

.010

.021

.027

.032

.059

.107

.117

.106

.210

.304

.458

.561

.796

1.233

.004

.005

.006

.007

.014

.019

.020

.024

.055

.064

.072

.111

.158

.303

.372

.545

.672

SERIES RATINGS

INDUCTANCE CURRENT

µH

ADC

1.69

3.01

4.70

9.21

18.80

31.77

42.30

60.91

82.91

99.45

127.09

204.73

271.47

397.81

589.57

794.30

1203.20

1.76

3.14

4.90

7.06

19.60

33.12

38.42

56.64

78.40

103.68

132.50

200.70

268.32

396.90

592.90

802.82

1192.46

3.25

2.75

2.30

2.25

1.50

1.30

1.25

.85

.65

.50

.70

.46

.39

.32

.22

.20

.19

3.50

3.00

2.50

2.95

2.20

1.75

1.70

1.50

1.05

1.00

.90

.75

.60

.46

.41

.32

.31

DCR

OHMS

.019

.024

.029

.038

.084

.108

.125

.237

.427

.466

.421

.839

1.214

1.829

2.242

3.184

4.929

.016

.020

.024

.028

.056

.073

.079

.096

.220

.254

.288

.444

.630

1.210

1.488

2.180

2.687

C MAX

(ALL IN INCHES)

.350

.460

.235

.450

.550

.275

XFMRS

XFMRS, INC.

1940 Landersdale Road • Camby, Indiana 46113 • Tel. (317) 834-1066 • Fax: (317) 834-1067
