Halogen and Antimony Free. “Green” Device (Note 3)
8
7
6
5
SET
NC
NC
V
IN
GND 4
U-DFN3030-10
( Top View )
CTRL
RSVD
NC
SW
1
2
3
4
5
10
9
SET
NC
NC
NC
V
IN
AP8800
8
7
6
Applications
Commercial & Industrial Lighting
Small LCD Panel Backlight
Architecture Detail Lighting
Appliances Interior Lighting
GND
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS), 2011/65/EU (RoHS 2) & 2015/863/EU (RoHS 3) compliant.
2. See https://www.diodes.com/quality/lead-free/ for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and
Lead-free.
3. Halogen and Antimony free "Green‖ products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl)
Switch Pin. Connect inductor/freewheeling diode here. Minimize trace area at this pin to
reduce EMI.
GND Pin
Set Nominal Output Current Pin. To configure the output current of the device.
Dual function dimming control pin.
Input voltage of 0.2V or lower forces the device into low current standby mode and
shuts off the output.
A PWM signal (driven by an open-drain/collector source) allows the output current
to be adjusted over a wide range up to 100%.
CTRL
1
1
1
An analog voltage between 0.3V and 2.5V adjusts the output current between 25%
and 200% of the current set by 0.2V/R
S
.
The input impedance is about 200kΩ, and if the pin is left open V
CTRL
= V
REF
V
IN
RSVD
NC
5
2
6, 7
5
2
6, 7
6
2
2, 7, 8, 9
Input Supply Pin. Must be locally bypassed.
Reserved. Normally connected to Ground
No Connection.
Functional Block Diagram
Absolute Maximum Ratings
(@T
A
= +25° unless otherwise specified.)
C,
Symbol
V
IN
V
SET
VSW
V
CTRL
T
J
T
LEAD
T
ST
Caution:
Parameter
VIN Pin Voltage
Set Voltage Relative to V
IN
SW Voltage
CTRL Pin Input Voltage
Maximum Junction Temperature
Maximum Lead Temperature
Storage Temperature Range
Rating
-0.3 to +30
V
IN
-5 to V
IN
+0.3
-0.3 to +30
-0.3 to +5
+125
+300
-55 to +125
Unit
V
V
V
V
°
C
°
C
°
C
