K30P144M100SF2: Description32-BIT, FLASH, 100 MHz, RISC MICROCONTROLLER, PBGA144; Categorysemiconductor The embedded processor and controller; File Size908KB，67 Pages; ManufacturerFREESCALE (NXP)

Download Datasheet Parametric Compare View All

K30P144M100SF2 Overview

32-BIT, FLASH, 100 MHz, RISC MICROCONTROLLER, PBGA144

K30P144M100SF2 Parametric

Parameter Name	Attribute value
Number of functions	1
Number of terminals	144
Maximum operating temperature	105 Cel
Minimum operating temperature	-40 Cel
Maximum supply/operating voltage	3.6 V
Minimum supply/operating voltage	1.71 V
Rated supply voltage	3.3 V
External data bus width	0.0
Number of input and output buses	100
Line speed	100 MHz
Processing package description	13 X 13 MM, MAPBGA-144
state	ACTIVE-UNCONFIRMED
packaging shape	SQUARE
Package Size	GRID ARRAY, LOW PROFILE
surface mount	Yes
Terminal form	BALL
Terminal spacing	1 mm
Terminal location	BOTTOM
Packaging Materials	PLASTIC/EPOXY
Temperature level	INDUSTRIAL
ADC channel	Yes
Address bus width	0.0
Number of digits	32
Maximum FCLK clock frequency	50 MHz
DAC channel	Yes
DMA channel	Yes
Microprocessor type	RISC MICROCONTROLLER
PWM channel	Yes
ROM programming	FLASH

Preview

Download Datasheet

View All

Freescale Semiconductor

Data Sheet: Product Preview

Document Number: K30P144M100SF2

Rev. 1, 11/2010

Features

• Operating Characteristics

– Voltage range: 1.71 to 3.6 V

– Flash write voltage range: 1.71 to 3.6 V

– Temperature range (ambient): -40 to 105°C

• Performance

– Up to 100 MHz ARM Cortex-M4 core with DSP

instructions delivering 1.25 Dhrystone MIPS per

MHz

• Memories and memory interfaces

– Up to 512 KB program flash memory on non-

FlexMemory devices

– Up to 256 KB program flash memory on

FlexMemory devices

– Up to 256 KB FlexNVM on FlexMemory devices

– 4 KB FlexRAM on FlexMemory devices

– Up to 128 KB RAM

– Serial programming interface (EzPort)

– FlexBus external bus interface

• Clocks

– 1 to 32 MHz crystal oscillator

– 32 kHz crystal oscillator

– Multi-purpose clock generator

• System peripherals

– 10 low-power modes to provide power optimization

based on application requirements

– Memory protection unit with multi-master

protection

– 16-channel DMA controller, supporting up to 64

request sources

– External watchdog monitor

– Software watchdog

– Low-leakage wakeup unit

This document contains information on a product under development. Freescale

reserves the right to change or discontinue this product without notice.

Preliminary

Supports the following:

MK30X128VLQ100,

MK30X128VMD100,

MK30X256VLQ100,

MK30X256VMD100,

MK30N512VLQ100,

MK30N512VMD100

K30 Sub-Family Data Sheet

K30P144M100SF2

• Security and integrity modules

– Hardware CRC module to support fast cyclic

redundancy checks

– 128-bit unique identification (ID) number per chip

• Human-machine interface

– Segment LCD controller supporting up to 40

frontplanes and 8 backplanes, or 44 frontplanes and

4 backplanes

– Low-power hardware touch sensor interface (TSI)

– General-purpose input/output

• Analog modules

– 16-bit SAR ADC with PGA (x64)

– 12-bit DAC

– Analog comparator (CMP) containing a 6-bit DAC

and programmable reference input

– Voltage reference

• Timers

– Programmable delay block

– Eight-channel motor control/general purpose/PWM

timers

– Two-channel quadrature decoder/general purpose

timers

– Periodic interrupt timers

– 16-bit low-power timer

– Carrier modulator transmitter

– Real-time clock

• Communication interfaces

– Controller Area Network (CAN) module

– SPI modules

– I2C modules

– UART modules

– Secure Digital host controller (SDHC)

– I2S

K30P144M100SF2 Related Products

	K30P144M100SF2	MK30X128VMD100	MK30X256VMD100	MK30X128VLQ100	MK30X256VLQ100
Description	32-BIT, FLASH, 100 MHz, RISC MICROCONTROLLER, PBGA144	32-BIT, FLASH, 100 MHz, RISC MICROCONTROLLER, PBGA144	32-BIT, FLASH, 100 MHz, RISC MICROCONTROLLER, PBGA144	32-BIT, FLASH, 100 MHz, RISC MICROCONTROLLER, PBGA144	32-BIT, FLASH, 100 MHz, RISC MICROCONTROLLER, PQFP144
Number of functions	1	1	1	1	1
Number of terminals	144	144	144	144	144
Maximum operating temperature	105 Cel	105 Cel	105 Cel	105 Cel	105 Cel
Minimum operating temperature	-40 Cel	-40 Cel	-40 Cel	-40 Cel	-40 Cel
Maximum supply/operating voltage	3.6 V	3.6 V	3.6 V	3.6 V	3.6 V
Minimum supply/operating voltage	1.71 V	1.71 V	1.71 V	1.71 V	1.71 V
Rated supply voltage	3.3 V	3.3 V	3.3 V	3.3 V	3.3 V
External data bus width	0.0	0.0	0.0	0.0	0.0
Number of input and output buses	100	100	100	100	100
Line speed	100 MHz	100 MHz	100 MHz	100 MHz	100 MHz
Processing package description	13 X 13 MM, MAPBGA-144	13 X 13 MM, MAPBGA-144	13 X 13 MM, MAPBGA-144	13 X 13 MM, MAPBGA-144	20 X 20 MM, LQFP-144
state	ACTIVE-UNCONFIRMED	ACTIVE-UNCONFIRMED	ACTIVE-UNCONFIRMED	ACTIVE-UNCONFIRMED	ACTIVE-UNCONFIRMED
packaging shape	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE
Package Size	GRID ARRAY, LOW PROFILE	GRID ARRAY, LOW PROFILE	GRID ARRAY, LOW PROFILE	GRID ARRAY, LOW PROFILE	FLATPACK, LOW PROFILE, FINE PITCH
surface mount	Yes	Yes	Yes	Yes	Yes
Terminal form	BALL	BALL	BALL	BALL	GULL WING
Terminal spacing	1 mm	1 mm	1 mm	1 mm	0.5000 mm
Terminal location	BOTTOM	BOTTOM	BOTTOM	BOTTOM	QUAD
Packaging Materials	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
ADC channel	Yes	Yes	Yes	Yes	Yes
Address bus width	0.0	0.0	0.0	0.0	0.0
Number of digits	32	32	32	32	32
Maximum FCLK clock frequency	50 MHz	50 MHz	50 MHz	50 MHz	50 MHz
DAC channel	Yes	Yes	Yes	Yes	Yes
DMA channel	Yes	Yes	Yes	Yes	Yes
Microprocessor type	RISC MICROCONTROLLER	RISC MICROCONTROLLER	RISC MICROCONTROLLER	RISC MICROCONTROLLER	RISC MICROCONTROLLER
PWM channel	Yes	Yes	Yes	Yes	Yes
ROM programming	FLASH	FLASH	FLASH	FLASH	FLASH
