010VAK datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Discrete semiconductor> 010VAK

010VAK: Description280 mA, 50 V, 2 CHANNEL, N-CHANNEL, Si, SMALL SIGNAL, MOSFET; Categorysemiconductor Discrete semiconductor; File Size445KB，7 Pages; ManufacturerDiodes; Websitehttp://www.diodes.com/

Download Datasheet Parametric Compare View All

010VAK Overview

280 mA, 50 V, 2 CHANNEL, N-CHANNEL, Si, SMALL SIGNAL, MOSFET

010VAK Parametric

Parameter Name	Attribute value
Number of terminals	6
Minimum breakdown voltage	50 V
Processing package description	GREEN, ULTRA SMALL, PLASTIC PACKAGE-6
Lead-free	Yes
EU RoHS regulations	Yes
China RoHS regulations	Yes
state	ACTIVE
packaging shape	RECTANGULAR
Package Size	SMALL OUTLINE
surface mount	Yes
Terminal form	FLAT
terminal coating	MATTE TIN
Terminal location	DUAL
Packaging Materials	PLASTIC/EPOXY
structure	SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE
Number of components	2
transistor applications	SWITCHING
Transistor component materials	SILICON
Channel type	N-CHANNEL
field effect transistor technology	METAL-OXIDE SEMICONDUCTOR
operating mode	ENHANCEMENT
Transistor type	GENERAL PURPOSE SMALL SIGNAL
Maximum leakage current	0.2800 A
feedback capacitor	5 pF
Maximum drain on-resistance	3 ohm

Preview

Download Datasheet

View All

DMN5/L06VK/L06VAK/010VAK

DUAL N-CHANNEL ENHANCEMENT MODE MOSFET

Features



Dual N-Channel MOSFET

Low On-Resistance

Very Low Gate Threshold Voltage, 1.0V Max

Low Input Capacitance

Fast Switching Speed

Low Input/Output Leakage

Ultra-Small Surface Mount Package

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

ESD Protected up to 2kV

Qualified to AEC-Q101 Standards for High Reliability

Mechanical Data



Case: SOT563

Case Material: Molded Plastic, ―Green‖ Molding Compound.

UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminal Connections: See Diagram

Terminals: Finish – Matte Tin Annealed over Copper Leadframe.

Solderable per MIL-STD-202, Method 208

Weight: 0.006 grams (Approximate)

ESD protected up to 2kV

SOT563

Top View

DMN5L06VK

DMN5L06VAK

DMN5010VAK

Ordering Information

(Note 4)

Part Number

DMN5L06VK-7

DMN5L06VK-7A

DMN5L06VK-13

DMN5L06VK-13A

DMN5L06VAK-7

DMN5L06VAK-7A

DMN5L06VAK-13

DMN5L06VAK-13A

DMN5010VAK-7

DMN5010VAK-7A

DMN5010VAK-13

DMN5010VAK-13A

Notes:

Case

SOT563

Packaging

3,000/Tape & Reel

10,000/Tape & Reel

3,000/Tape & Reel

10,000/Tape & Reel

3,000/Tape & Reel

10,000/Tape & Reel

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green‖ products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

For packaging details, go to our website at http://www.diodes.com/products/packages.html.

DMN5/L06VK/L06VAK/010VAK

Document number: DS30769 Rev. 13 - 2

1 of 7

www.diodes.com

February 2017
